AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme
vs
NVIDIA GeForce RTX 4050 Mobile (Laptop GPU)
GPU comparison with benchmarksThe AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme has 768 shader units and these clock a maximum of 2.90 GHz which results in an FP32 computing power of 8.91 TFLOPS.
The NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) has 2560 shader units and these clock at a maximum of 2.36 GHz and achieve an FP32 computing power of 12.06 TFLOPS. |
||
GPUThe AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme is equipped with a graphics chip of the RDNA 3 architecture, which has 12 streaming multiprocessors. The graphics card NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) is based on the Ada Lovelace architecture and is equipped with 20 execution units. |
||
| AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme | GPU | NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) |
| AMD Radeon 780M Graphics | Based on | NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) |
| Phoenix | GPU Chip | AD107 |
| RDNA 3 | Architecture | Ada Lovelace |
| 12 | Streaming Multiprocessors | 20 |
| 768 | Shader | 2560 |
| 32 | Render Output Units | 48 |
| 48 | Texture Units | 80 |
| 12 | Raytracing Cores | 20 |
MemoryThe AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme is equipped with a 32 GB large LPDDR5X graphics memory, which is equipped with 3.750 GHz clocks. The NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) has a 6 GB large GDDR6 graphics memory and the memory clock is 2.000GHz. |
||
| 32 GB | Memory Size | 6 GB |
| LPDDR5X | Memory Type | GDDR6 |
| 3.750 GHz | Memory Clock | 2.000 GHz |
| 0.0 Gbps | Memory Speed | 16.0 Gbps |
| 90 GB/s | Memory bandwidth | 192 GB/s |
| 0 bit | Memory Interface | 96 bit |
Clock SpeedsThe AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme has a turbo clock of 2.900 GHz. The turbo frequency of the NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) is 2.355 GHz. |
||
| 1.500 GHz | Base Clock | 2.070 GHz |
| 2.900 GHz | Boost Clock | 2.355 GHz |
| Avg (Game) Clock | ||
| No | Overclocking | No |
Thermal DesignThe AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme has connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as Unknown. The NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) is equipped with a PCIe power connector that supplies it with power. The maximum operating temperature of the card is Unknown. |
||
| 15 W (Reference) | TDP | 110 W |
| -- | TDP (up) | -- |
| Unknown | Tjunction max | Unknown |
| PCIe-Power | ||
Cooler & FansThe graphics processor and graphics memory of the AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme are cooled with a Air cooling. The NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) is cooled by a --. |
||
| -- | Fan-Type | -- |
| -- | Fan 1 | -- |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | -- |
| -- | Noise (Idle) | dB |
| -- | Noise (Load) | -- |
ConnectivityThe AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme supports the downward compatible copy protection HDCP in version --. The NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) supports HDCP in version 2.3 and all previous versions. |
||
| 4 | Max. Displays | 4 |
| -- | HDCP-Version | 2.3 |
| -- | HDMI Ports | -- |
| -- | DP Ports | -- |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme supports the DirectX standard from Microsoft in version 12. The NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) supports Microsoft's DirectX version 12_2 (Ultimate). |
||
| 3840x2160 | Max. resolution | 7680x4320 |
| 12 | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | No LED lighting |
Supported Video CodecsThis area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode / Encode | AV1 | Decode / Encode |
| Decode | VP8 | Decode |
| Decode | VP9 | Decode |
DimensionsThe AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme is -- wide and therefore needs the space of -- in the case. The width of the NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) is -- and thus requires the space of -- in the PC case. |
||
| -- | Length | -- |
| -- | Height | -- |
| -- | Width | -- |
| -- | Width (Slots) | -- |
| -- | Weight | -- |
| Integrated graphics | GPU Interface | PCIe 4.0 x 16 |
| No | SFF-Ready | No |
Additional dataManufactured using the 4 nanometer process, AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme was released in Q1/2023. The NVIDIA GeForce RTX 4050 Mobile (Laptop GPU) published in Q1/2023 is manufactured with a structure width of 4 nanometers. |
||
| -- | Part-no | -- |
| Q1/2023 | Release date | Q1/2023 |
| -- | Launch Price | -- |
| 4 nm | Structure size | 4 nm |
| -- | Documents | -- |
1.500 GHz, 32 GB (-- TDP)
Buy this graphic card at amazon!
2.070 GHz, 6 GB (110 W TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Port Royal (Raytracing)
|
NVIDIA GeForce RTX 4050 Mobile (Laptop GPU)
6 GB GDDR6 |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
2560x1440 (1440p)
|
|
NVIDIA GeForce RTX 4050 Mobile (Laptop GPU)
6 GB GDDR6 |
||
The Last of Us Part 1
The Last of Us Part One is a game released by Sony in June 2013 exclusively for the Playstation and released for the PC in early 2023. The benchmark values here were determined at high details.
2560x1440 (1440p)
|
|
NVIDIA GeForce RTX 4050 Mobile (Laptop GPU)
6 GB GDDR6 |
||
1920x1080 (1080p)
|
|
NVIDIA GeForce RTX 4050 Mobile (Laptop GPU)
6 GB GDDR6 |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
NVIDIA GeForce RTX 4050 Mobile (Laptop GPU)
6 GB GDDR6 |
||
Geekbench 6 - Vulkan
|
|
NVIDIA GeForce RTX 4050 Mobile (Laptop GPU)
6 GB GDDR6 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
AMD Radeon 780M Graphics - ASUS ROG Ally Z1 Extreme
32 GB LPDDR5X |
||
|
|
NVIDIA GeForce RTX 4050 Mobile (Laptop GPU)
6 GB GDDR6 |
||
