MSI GeForce RTX 5090 SUPRIM SOC
vs
MSI GeForce RTX 5090 SUPRIM LIQUID SOC
GPU comparison with benchmarksIn the gpu comparison between the MSI GeForce RTX 5090 SUPRIM SOC and the MSI GeForce RTX 5090 SUPRIM LIQUID SOC, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe MSI GeForce RTX 5090 SUPRIM SOC is based on the NVIDIA GeForce RTX 5090 and has 21760 texture shaders and 170 execution units. MSI GeForce RTX 5090 SUPRIM LIQUID SOC is based on NVIDIA GeForce RTX 5090, which has 21760 shaders and 170 execution units. |
||
| MSI GeForce RTX 5090 SUPRIM SOC | GPU | MSI GeForce RTX 5090 SUPRIM LIQUID SOC |
| NVIDIA GeForce RTX 5090 | Based on | NVIDIA GeForce RTX 5090 |
| GB202-300-A1 | GPU Chip | GB202-300-A1 |
| Blackwell | Architecture | Blackwell |
| 170 | Streaming Multiprocessors | 170 |
| 21760 | Shader | 21760 |
| 176 | Render Output Units | 176 |
| 680 | Texture Units | 680 |
| 170 | Raytracing Cores | 170 |
MemoryThe MSI GeForce RTX 5090 SUPRIM SOC has 32 GB of graphics memory of the type GDDR7 and achieves a memory bandwidth of 1792 GB/s. The MSI GeForce RTX 5090 SUPRIM LIQUID SOC can access 32 GB GDDR7 graphics memory and thus achieves a memory bandwidth of 1792 GB/s. |
||
| 32 GB | Memory Size | 32 GB |
| GDDR7 | Memory Type | GDDR7 |
| 1.750 GHz | Memory Clock | 1.750 GHz |
| 28.0 Gbps | Memory Speed | 28.0 Gbps |
| 1792 GB/s | Memory bandwidth | 1792 GB/s |
| 512 bit | Memory Interface | 512 bit |
Clock SpeedsThe MSI GeForce RTX 5090 SUPRIM SOC clocks in the base with up to 2.017 GHz. The base frequency of the MSI GeForce RTX 5090 SUPRIM LIQUID SOC is 2.017 GHz. |
||
| 2.017 GHz | Base Clock | 2.017 GHz |
2.580 GHz + 7 % |
Boost Clock | 2.580 GHz+ 7 % |
| Avg (Game) Clock | ||
| Yes | Overclocking | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the MSI GeForce RTX 5090 SUPRIM SOC is 575 W. The graphics card is supplied with energy via the 1 x 16-Pin connector. The MSI GeForce RTX 5090 SUPRIM LIQUID SOC has a TDP of 575 W and is supplied with the required energy via 1 x 16-Pin PCIe power connectors. |
||
| 575 W | TDP | 575 W |
| 600 W | TDP (up) | -- |
| 90 °C | Tjunction max | 90 °C |
| 1 x 16-Pin | PCIe-Power | 1 x 16-Pin |
Cooler & FansThe MSI GeForce RTX 5090 SUPRIM SOC has a total of 3 Axial fans. The MSI GeForce RTX 5090 SUPRIM LIQUID SOC has 4 Axial / Axial (Radiator) fans to cool the GPU and memory. |
||
| Axial | Fan-Type | Axial / Axial (Radiator) |
| 3 x 110 mm | Fan 1 | 1 x 100 mm |
| -- | Fan 2 | 3 x 120 mm |
| Air cooling | Cooler-Type | Air cooling |
| 0 dB | Noise (Idle) | 0 dB |
| -- | Noise (Load) | -- |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 4 screens can be connected to the MSI GeForce RTX 5090 SUPRIM SOC. The MSI GeForce RTX 5090 SUPRIM LIQUID SOC supports a maximum of 4 screens. |
||
| 4 | Max. Displays | 4 |
| 2.3 | HDCP-Version | 2.3 |
| 1x HDMI v2.1b | HDMI Ports | 1x HDMI v2.1b |
| 3x DP v2.1b | DP Ports | 3x DP v2.1b |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe MSI GeForce RTX 5090 SUPRIM SOC supports a maximum resolution of 7680x4320 pixels. The maximum resolution of the MSI GeForce RTX 5090 SUPRIM LIQUID SOC is 7680x4320 pixels. |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| MSI Mystic Light | LED | MSI Mystic Light |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode / Encode | AV1 | Decode / Encode |
| Decode / Encode | VP8 | Decode / Encode |
| Decode / Encode | VP9 | Decode / Encode |
DimensionsThe MSI GeForce RTX 5090 SUPRIM SOC is 359 mm long, 150 mm high and 76 mm wide. The MSI GeForce RTX 5090 SUPRIM LIQUID SOC is 280 mm long, 148 mm high and 51 mm wide. |
||
| 359 mm | Length | 280 mm |
| 150 mm | Height | 148 mm |
| 76 mm | Width | 51 mm |
| 4 PCIe-Slots | Width (Slots) | 3 PCIe-Slots |
| 2840 g | Weight | 2969 g |
| PCIe 5 x 16 | GPU Interface | PCIe 5 x 16 |
| No | SFF-Ready | No |
Additional dataThe MSI GeForce RTX 5090 SUPRIM SOC was released in Q1/2025 at a price of 2,329 $ (Reference). The MSI GeForce RTX 5090 SUPRIM LIQUID SOC was introduced in Q1/2025 at a price of 2,329 $ (Reference). |
||
| -- | Part-no | -- |
| Q1/2025 | Release date | Q1/2025 |
| 2,329 $ (Reference) | Launch Price | 2,329 $ (Reference) |
| 5 nm | Structure size | 5 nm |
| data sheet | Documents | data sheet |
2.017 GHz, 32 GB (575 W TDP)
Buy this graphic card at amazon!
2.017 GHz, 32 GB (575 W TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
MSI GeForce RTX 5090 SUPRIM SOC
32 GB GDDR7 |
||
|
|
MSI GeForce RTX 5090 SUPRIM LIQUID SOC
32 GB GDDR7 |
||
