GPU comparison with benchmarksThe PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition has 5888 shader units and these clock a maximum of 1.73 GHz which results in an FP32 computing power of 20.31 TFLOPS.
The EVGA GeForce GTX 1070 Ti FTW2 GAMING has 2432 shader units and these clock at a maximum of 1.68 GHz and achieve an FP32 computing power of 8.19 TFLOPS. |
||
GPUThe PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition is equipped with a graphics chip of the Ampere architecture, which has 46 streaming multiprocessors. The graphics card EVGA GeForce GTX 1070 Ti FTW2 GAMING is based on the Pascal architecture and is equipped with 199 execution units. |
||
PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition | GPU | EVGA GeForce GTX 1070 Ti FTW2 GAMING |
NVIDIA GeForce RTX 3070 | Based on | NVIDIA GeForce GTX 1070 Ti |
GA104-300-A1 | GPU Chip | GP104-300-A1 |
Ampere | Architecture | Pascal |
46 | Streaming Multiprocessors | 199 |
5888 | Shader | 2432 |
96 | Render Output Units | 64 |
184 | Texture Units | 152 |
46 | Raytracing Cores | 0 |
MemoryThe PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition is equipped with a 8 GB large GDDR6 graphics memory, which is equipped with 1.750 GHz clocks. The EVGA GeForce GTX 1070 Ti FTW2 GAMING has a 8 GB large GDDR5 graphics memory and the memory clock is 2.002GHz. |
||
8 GB | Memory Size | 8 GB |
GDDR6 | Memory Type | GDDR5 |
1.750 GHz | Memory Clock | 2.002 GHz |
14.0 Gbps | Memory Speed | 8.0 Gbps |
448 GB/s | Memory bandwidth | 256 GB/s |
256 bit | Memory Interface | 256 bit |
Clock SpeedsThe PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition has a turbo clock of 1.725 GHz. The turbo frequency of the EVGA GeForce GTX 1070 Ti FTW2 GAMING is 1.683 GHz. |
||
1.500 GHz | Base Clock | 1.607 GHz |
1.725 GHz | Boost Clock | 1.683 GHz |
Avg (Game) Clock | ||
Yes | Overclocking | Yes |
Thermal DesignThe PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition has 2 x 8-Pin connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as 93 °C. The EVGA GeForce GTX 1070 Ti FTW2 GAMING is equipped with a 2 x 8-Pin PCIe power connector that supplies it with power. The maximum operating temperature of the card is 94 °C. |
||
220 W | TDP | 180 W |
240 W | TDP (up) | -- |
93 °C | Tjunction max | 94 °C |
2 x 8-Pin | PCIe-Power | 2 x 8-Pin |
Cooler & FansThe graphics processor and graphics memory of the PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition are cooled with a Air cooling. The EVGA GeForce GTX 1070 Ti FTW2 GAMING is cooled by a Air cooling. |
||
Axial | Fan-Type | Axial |
3 x 90 mm | Fan 1 | 2 x 100 mm |
-- | Fan 2 | -- |
Air cooling | Cooler-Type | Air cooling |
0 dB | Noise (Idle) | dB |
42 dB | Noise (Load) | -- |
ConnectivityThe PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition supports the downward compatible copy protection HDCP in version 2.3. The EVGA GeForce GTX 1070 Ti FTW2 GAMING supports HDCP in version 2.2 and all previous versions. |
||
4 | Max. Displays | 4 |
2.3 | HDCP-Version | 2.2 |
1x HDMI v2.1 | HDMI Ports | 1x HDMI v2.0b |
3x DP v1.4a | DP Ports | 3x DP v1.4 |
-- | DVI Ports | 1 |
-- | VGA Ports | -- |
-- | USB-C Ports | -- |
FeaturesetThe PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition supports the DirectX standard from Microsoft in version 12_2 (Ultimate). The EVGA GeForce GTX 1070 Ti FTW2 GAMING supports Microsoft's DirectX version 12_1. |
||
7680x4320 | Max. resolution | 7680x4320 |
12_2 (Ultimate) | DirectX | 12_1 |
Yes | Raytracing | No |
Yes | DLSS / FSR | Yes |
Addressable LED | LED | No LED lighting |
Supported Video CodecsThis area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load. |
||
Decode / Encode | h264 | Decode / Encode |
Decode / Encode | h265 / HEVC | Decode / Encode |
Decode | AV1 | No |
Decode | VP8 | Decode |
Decode | VP9 | Decode |
DimensionsThe PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition is 56 mm wide and therefore needs the space of 2 PCIe-Slots in the case. The width of the EVGA GeForce GTX 1070 Ti FTW2 GAMING is 56 mm and thus requires the space of 2 PCIe-Slots in the PC case. |
||
294 mm | Length | 267 mm |
112 mm | Height | 129 mm |
56 mm | Width | -- |
3 PCIe-Slots | Width (Slots) | 2 PCIe-Slots |
-- | Weight | -- |
PCIe 4.0 x 16 | GPU Interface | PCIe 3.0 x 16 |
Additional dataManufactured using the 8 nanometer process, PNY GeForce RTX 3070 XLR8 Gaming Revel Epic-X RGB Triple Fan Edition was released in Q4/2020. The EVGA GeForce GTX 1070 Ti FTW2 GAMING published in Q4/2017 is manufactured with a structure width of 16 nanometers. |
||
VCG30708TFXPPB | Part-no | 08G-P4-6775-KR |
Q4/2020 | Release date | Q4/2017 |
549 $ | Launch Price | 449 $ (Reference) |
8 nm | Structure size | 16 nm |
data sheet | Documents | data sheet |
