Intel Arc A380 Graphics
GPU |
|
| GPU Chip: | ACM-G11 |
| Streaming Multiprocessors: | 128 |
| Shader: | 1024 |
| Render Output Units: | 32 |
| Texture Units: | 64 |
| Raytracing Cores: | 8 |
| FP32: | 4.10 TFLOPS |
Memory |
|
| Memory Size: | 6 GB |
| Memory Type: | GDDR6 |
| Memory Clock: | 1.938 GHz |
| Memory Speed: | 15.5 Gbps |
| Memory bandwidth: | 186 GB/s |
| Memory Interface: | 96 bit |
Clock Speeds |
|
| Base Clock: | 2.250 GHz |
| Boost Clock: | -- |
| Avg (Game) Clock: | -- |
Thermal Design |
|
| TDP: | 75 W |
| TDP (up): | -- |
Featureset |
|
| Max. Displays: | 4 |
| Max. resolution: | 7680x4320 |
| DirectX: | 12_2 (Ultimate) |
| Raytracing: | Yes |
| DLSS / FSR: | Yes |
Supported Video Codecs |
|
| h264: | Decode / Encode |
| h265 / HEVC: | Decode / Encode |
| VP8: | No |
| VP9: | Decode / Encode |
| AV1: | Decode / Encode |
Additional data |
|
| Manufacturer: | Intel |
| Architecture: | Alchemist |
| GPU Interface: | PCIe 4.0 x 8 |
| Structure size: | 6 nm |
| Release date: | Q3/2022 |
| Launch Price: | -- |
Benchmark results
3DMark Benchmark (DirectX, Raytracing) - Time Spy Extreme Graphics score
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
|
NVIDIA GeForce GTX 1650 SUPER
4 GB GDDR6 |
||
|
|
NVIDIA GeForce GTX 980
4 GB GDDR5 |
||
|
AMD Radeon RX 580 (36 CU)
8 GB GDDR5 |
||
|
Intel Arc A380 Graphics
6 GB GDDR6 |
||
|
|
NVIDIA GeForce GTX 1060 6GB
6 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB (GDDR5X)
6 GB GDDR5X |
||
|
|
AMD Radeon RX 480
8 GB GDDR5 |
||
3DMark Benchmark (DirectX, Raytracing) - Port Royal (Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.|
|
NVIDIA GeForce GTX 1660 SUPER
6 GB GDDR6 |
||
|
|
NVIDIA GeForce GTX 1070 Ti
8 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1660
6 GB GDDR5 |
||
|
|
Intel Arc A380 Graphics
6 GB GDDR6 |
||
|
|
NVIDIA GeForce GTX 1070
8 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB
6 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB (GDDR5X)
6 GB GDDR5X |
||
TOP 5 GPUs in group by FP32 performance
| 1. |
|
ASRock Intel Arc A380 Challenger ITX 6GB OC | 4.10 TFLOPS | |
| 2. |
|
Intel Arc A380 Graphics | 4.10 TFLOPS | |
| 3. |
|
Matrox LUMA A380 | 3.74 TFLOPS | |
| 4. |
|
ASRock Intel Arc A380 Low Profile 6GB | 3.64 TFLOPS | |
| 5. |
|
SPARKLE Intel Arc A380 ELF | 3.64 TFLOPS |
TOP 5 GPUs in group by maximum TDP
| 1. |
|
ASRock Intel Arc A380 Challenger ITX 6GB OC | 75 W | |
| 2. |
|
Intel Arc A380 Graphics | 75 W | |
| 3. |
|
ASRock Intel Arc A380 Low Profile 6GB | 0 W | |
| 4. |
|
Matrox LUMA A380 | 0 W | |
| 5. |
|
SPARKLE Intel Arc A380 ELF | 0 W |
