Note: The information shown below is based on a pre-sample. Technical details or benchmark results may be different in the final version of this product. |
Intel Arc A580 Graphics
GPU |
|
| GPU Chip: | ACM-G10 |
| Streaming Multiprocessors: | 384 |
| Shader: | 3072 |
| Render Output Units: | 96 |
| Texture Units: | 192 |
| Raytracing Cores: | 24 |
| FP32: | 10.44 TFLOPS |
Memory |
|
| Memory Size: | 8 GB |
| Memory Type: | GDDR6 |
| Memory Clock: | 2 GHz |
| Memory Speed: | 16 Gbps |
| Memory bandwidth: | 512 GB/s |
| Memory Interface: | 256 bit |
Clock Speeds |
|
| Base Clock: | 1.700 GHz |
| Boost Clock: | -- |
| Avg (Game) Clock: | -- |
Thermal Design |
|
| TDP: | 175 W |
| TDP (up): | -- |
Featureset |
|
| Max. Displays: | 4 |
| Max. resolution: | 7680x4320 |
| DirectX: | 12_2 (Ultimate) |
| Raytracing: | Yes |
| DLSS / FSR: | No |
Supported Video Codecs |
|
| h264: | Decode / Encode |
| h265 / HEVC: | Decode / Encode |
| VP8: | No |
| VP9: | Decode / Encode |
| AV1: | Decode / Encode |
Additional data |
|
| Manufacturer: | Intel |
| Architecture: | Alchemist |
| GPU Interface: | PCIe 4.0 x 16 |
| Structure size: | 6 nm |
| Release date: | Q3/2022 |
| Launch Price: | -- |
Benchmark results
TOP 5 GPUs in group by FP32 performance
| 1. |
|
Intel Arc A580 Graphics | 10.44 TFLOPS |
TOP 5 GPUs in group by maximum TDP
| 1. |
|
Intel Arc A580 Graphics | 175 W |
