Note: The information shown below is based on a pre-sample. Technical details or benchmark results may be different in the final version of this product. |
GPU |
|
GPU Chip: | AD107 |
Streaming Multiprocessors: | 24 |
Shader: | 3072 |
Render Output Units: | 32 |
Texture Units: | 96 |
Raytracing Cores: | 24 |
FP32: | 15.11 TFLOPS |
Memory |
|
Memory Size: | 8 GB |
Memory Type: | GDDR6 |
Memory Clock: | 2.125 GHz |
Memory Speed: | 17 Gbps |
Memory bandwidth: | 272 GB/s |
Memory Interface: | 128 bit |
Clock Speeds |
|
Base Clock: | 1.830 GHz |
Boost Clock: | 2.460 GHz |
Avg (Game) Clock: | -- |
Thermal Design |
|
TDP: | 115 W |
TDP (up): | -- |
Featureset |
|
Max. Displays: | 4 |
Max. resolution: | 7680x4320 |
DirectX: | 12_2 (Ultimate) |
Raytracing: | Yes |
DLSS / FSR: | Yes |
Supported Video Codecs |
|
h264: | Decode / Encode |
h265 / HEVC: | Decode / Encode |
VP8: | Decode |
VP9: | Decode |
AV1: | Decode / Encode |
Additional data |
|
Manufacturer: | NVIDIA |
Architecture: | Ada Lovelace |
GPU Interface: | PCIe 4.0 x 8 |
Structure size: | 4 nm |
Release date: | Q3/2023 |
Launch Price: | 299 $ |
