MSI GeForce RTX 2080 Ti Ventus GP OC
vs
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
GPU comparison with benchmarksThe MSI GeForce RTX 2080 Ti Ventus GP OC is based on the NVIDIA GeForce RTX 2080 Ti (Turing) and has 11 GB GDDR6 graphics memory with a bandwidth of 616 GB/s.
The ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition is based on the NVIDIA GeForce RTX 2060 SUPER (Turing) and has 8 GB GDDR6 graphics memory with a bandwidth of 448 GB/s. |
||
GPUThe MSI GeForce RTX 2080 Ti Ventus GP OC has the TU102 graphics chip installed, which is based on the Turing architecture. The ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition is based on the graphics chip TU106, which comes from the Turing architecture. |
||
| MSI GeForce RTX 2080 Ti Ventus GP OC | GPU | ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition |
| NVIDIA GeForce RTX 2080 Ti | Based on | NVIDIA GeForce RTX 2060 SUPER |
| TU102 | GPU Chip | TU106 |
| Turing | Architecture | Turing |
| 68 | Streaming Multiprocessors | 34 |
| 4352 | Shader | 2176 |
| 88 | Render Output Units | 64 |
| 272 | Texture Units | 136 |
| 68 | Raytracing Cores | 34 |
MemoryThe graphics memory of the MSI GeForce RTX 2080 Ti Ventus GP OC clocks at 1.750 GHz, which corresponds to a speed of 14.0 Gbps. The graphics memory speed of the ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition is 14.0 Gbps and the clock speed is 1.750 GHz. |
||
| 11 GB | Memory Size | 8 GB |
| GDDR6 | Memory Type | GDDR6 |
| 1.750 GHz | Memory Clock | 1.750 GHz |
| 14.0 Gbps | Memory Speed | 14.0 Gbps |
| 616 GB/s | Memory bandwidth | 448 GB/s |
| 352 bit | Memory Interface | 256 bit |
Clock SpeedsThe clock frequency of a graphics card determines the speed in connection with the graphics architecture. |
||
| 1.350 GHz | Base Clock | 1.470 GHz |
| 1.635 GHz | Boost Clock | 1.695 GHz |
| 1.55 GHz | Avg (Game) Clock | 1.67 GHz |
| Yes | Overclocking | Yes |
Thermal DesignThe MSI GeForce RTX 2080 Ti Ventus GP OC is powered by 2 x 8-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 250 W. The ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition has 1 x 8-Pin PCIe power connectors that supply it with energy. The manufacturer specifies the TDP of the card as 175 W. |
||
| 250 W | TDP | 175 W |
| 320 W | TDP (up) | -- |
| 89 °C | Tjunction max | 89 °C |
| 2 x 8-Pin | PCIe-Power | 1 x 8-Pin |
Cooler & FansThe MSI GeForce RTX 2080 Ti Ventus GP OC is equipped with a total of 2 Axial main fans. The ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition has 2 Axial main fans that cool the GPU and memory. |
||
| Axial | Fan-Type | Axial |
| 2 x 90 mm | Fan 1 | 2 x 90 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| 0 dB | Noise (Idle) | 0 dB |
| 42-43 dB | Noise (Load) | -- |
ConnectivityUp to 4 screens can be operated with the MSI GeForce RTX 2080 Ti Ventus GP OC. The ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition supports the operation of a maximum of 4 monitors. |
||
| 4 | Max. Displays | 4 |
| 2.2 | HDCP-Version | 2.2 |
| 1x HDMI v2.0b | HDMI Ports | 2x HDMI v2.0b |
| 3x DP v1.4a | DP Ports | -- |
| -- | DVI Ports | 1 |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetWith the MSI GeForce RTX 2080 Ti Ventus GP OC it is possible to operate a screen with a maximum resolution of up to 7680x4320 pixels. The maximum supported resolution of the ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition is 7680x4320 pixels. |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | No LED lighting |
Supported Video CodecsThe support and acceleration of certain video codecs can have a positive impact on the lower energy consumption and less waste heat from the graphics card. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| No | AV1 | No |
| Decode | VP8 | Decode |
| Decode | VP9 | Decode |
DimensionsThe MSI GeForce RTX 2080 Ti Ventus GP OC is connected to the system via PCIe 3.0 x 16 lanes and requires 3 PCIe-Slots space in the housing. The ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition needs the space of 3 PCIe-Slots in the case and has a PCIe 3.0 x 16 Lanes interface. |
||
| 268 mm | Length | 242 mm |
| 112 mm | Height | 130 mm |
| 50 mm | Width | 53 mm |
| 3 PCIe-Slots | Width (Slots) | 3 PCIe-Slots |
| 1087 g | Weight | -- |
| PCIe 3.0 x 16 | GPU Interface | PCIe 3.0 x 16 |
Additional dataThe MSI GeForce RTX 2080 Ti Ventus GP OC has been manufactured with a structure width of 12 nanometers since Q3/2018. The ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition came on the market in Q4/2019 and will have a structure width of 12 nanometers manufactured. |
||
| -- | Part-no | DUAL-RTX2060S-A8G-EVO-V2 |
| Q3/2018 | Release date | Q4/2019 |
| 1,599 $ | Launch Price | 399 $ (Reference) |
| 12 nm | Structure size | 12 nm |
| data sheet | Documents | data sheet |
1.350 GHz, 11 GB (250 W TDP)
Buy this graphic card at amazon!
1.470 GHz, 8 GB (175 W TDP)
Buy this graphic card at amazon!
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.Time Spy Extreme Graphics score
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
Port Royal (Raytracing)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
Speed Way Graphics Score (Raytracing)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.3840x2160 (2160p)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
2560x1440 (1440p)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
The Last of Us Part 1
The Last of Us Part One is a game released by Sony in June 2013 exclusively for the Playstation and released for the PC in early 2023. The benchmark values here were determined at high details.2560x1440 (1440p)
1920x1080 (1080p)
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.3840x2160 (2160p)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
2560x1440 (1440p)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.FP32 (TFLOPS)
|
|
MSI GeForce RTX 2080 Ti Ventus GP OC
11 GB GDDR6 |
||
|
|
ASUS Dual GeForce RTX 2060 SUPER EVO V2 Advanced Edition
8 GB GDDR6 |
||
