ASRock Radeon RX 9060 XT Challenger 16GB OC
vs
ASRock Radeon RX 9060 XT Challenger 16GB
GPU comparison with benchmarksIn the gpu comparison between the ASRock Radeon RX 9060 XT Challenger 16GB OC and the ASRock Radeon RX 9060 XT Challenger 16GB, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe ASRock Radeon RX 9060 XT Challenger 16GB OC is based on the AMD Radeon RX 9060 XT 16GB and has 2048 texture shaders and 32 execution units. ASRock Radeon RX 9060 XT Challenger 16GB is based on AMD Radeon RX 9060 XT 16GB, which has 2048 shaders and 32 execution units. |
||
| ASRock Radeon RX 9060 XT Challenger 16GB OC | GPU | ASRock Radeon RX 9060 XT Challenger 16GB |
| AMD Radeon RX 9060 XT 16GB | Based on | AMD Radeon RX 9060 XT 16GB |
| Navi 44 XT | GPU Chip | Navi 44 XT |
| RDNA 4 | Architecture | RDNA 4 |
| 32 | Streaming Multiprocessors | 32 |
| 2048 | Shader | 2048 |
| 64 | Render Output Units | 64 |
| 128 | Texture Units | 128 |
| 32 | Raytracing Cores | 32 |
MemoryThe ASRock Radeon RX 9060 XT Challenger 16GB OC has 16 GB of graphics memory of the type GDDR6 and achieves a memory bandwidth of 322 GB/s. The ASRock Radeon RX 9060 XT Challenger 16GB can access 16 GB GDDR6 graphics memory and thus achieves a memory bandwidth of 322 GB/s. |
||
| 16 GB | Memory Size | 16 GB |
| GDDR6 | Memory Type | GDDR6 |
| 2.518 GHz | Memory Clock | 2.518 GHz |
| 20.1 Gbps | Memory Speed | 20.1 Gbps |
| 322 GB/s | Memory bandwidth | 322 GB/s |
| 128 bit | Memory Interface | 128 bit |
Clock SpeedsThe ASRock Radeon RX 9060 XT Challenger 16GB OC clocks in the base with up to 1.700 GHz. The base frequency of the ASRock Radeon RX 9060 XT Challenger 16GB is 1.700 GHz. |
||
| 1.700 GHz | Base Clock | 1.700 GHz |
3.290 GHz + 5 % |
Boost Clock | 3.230 GHz+ 3 % |
| 2.70 GHz+ 7 % |
Avg (Game) Clock | 2.62 GHz+ 4 % |
| Yes | Overclocking | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the ASRock Radeon RX 9060 XT Challenger 16GB OC is 160 W (Reference). The graphics card is supplied with energy via the 1 x 8-Pin connector. The ASRock Radeon RX 9060 XT Challenger 16GB has a TDP of 160 W (Reference) and is supplied with the required energy via 1 x 8-Pin PCIe power connectors. |
||
| 160 W (Reference) | TDP | 160 W (Reference) |
| -- | TDP (up) | -- |
| Unknown | Tjunction max | Unknown |
| 1 x 8-Pin | PCIe-Power | 1 x 8-Pin |
Cooler & FansThe ASRock Radeon RX 9060 XT Challenger 16GB OC has a total of 2 Axial fans. The ASRock Radeon RX 9060 XT Challenger 16GB has 2 Axial fans to cool the GPU and memory. |
||
| Axial | Fan-Type | Axial |
| 2 x 100 mm | Fan 1 | 2 x 100 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| 0 dB | Noise (Idle) | 0 dB |
| -- | Noise (Load) | -- |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 4 screens can be connected to the ASRock Radeon RX 9060 XT Challenger 16GB OC. The ASRock Radeon RX 9060 XT Challenger 16GB supports a maximum of 4 screens. |
||
| 4 | Max. Displays | 4 |
| 2.3 | HDCP-Version | 2.3 |
| 1x HDMI v2.1b | HDMI Ports | 1x HDMI v2.1b |
| 2x DP v2.1a | DP Ports | 2x DP v2.1a |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe ASRock Radeon RX 9060 XT Challenger 16GB OC supports a maximum resolution of 7680x4320 pixels. The maximum resolution of the ASRock Radeon RX 9060 XT Challenger 16GB is 7680x4320 pixels. |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | No LED lighting |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode / Encode | AV1 | Decode / Encode |
| Decode / Encode | VP8 | Decode / Encode |
| Decode / Encode | VP9 | Decode / Encode |
DimensionsThe ASRock Radeon RX 9060 XT Challenger 16GB OC is 249 mm long, 132 mm high and 41 mm wide. The ASRock Radeon RX 9060 XT Challenger 16GB is 249 mm long, 132 mm high and 41 mm wide. |
||
| 249 mm | Length | 249 mm |
| 132 mm | Height | 132 mm |
| 41 mm | Width | 41 mm |
| 2 PCIe-Slots | Width (Slots) | 2 PCIe-Slots |
| 645 g | Weight | 645 g |
| PCIe 5 x 16 | GPU Interface | PCIe 5 x 16 |
| No | SFF-Ready | No |
Additional dataThe ASRock Radeon RX 9060 XT Challenger 16GB OC was released in Q2/2025 at a price of 349 $. The ASRock Radeon RX 9060 XT Challenger 16GB was introduced in Q4/2025 at a price of 349 $ (Reference). |
||
| RX9060XT CL 16GO | Part-no | RX9060XT CL 16G |
| Q2/2025 | Release date | Q4/2025 |
| 349 $ | Launch Price | 349 $ (Reference) |
| 4 nm | Structure size | 4 nm |
| data sheet | Documents | data sheet |
1.700 GHz, 16 GB (-- TDP)
Buy this graphic card at amazon!
1.700 GHz, 16 GB (-- TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
ASRock Radeon RX 9060 XT Challenger 16GB OC
16 GB GDDR6 |
||
|
|
ASRock Radeon RX 9060 XT Challenger 16GB
16 GB GDDR6 |
||
