GALAX GeForce RTX 2080 OC White
vs
INNO3D GeForce RTX 2080 GAMING X2 OC
GPU comparison with benchmarksThe GALAX GeForce RTX 2080 OC White has 2944 shader units and these clock a maximum of 1.80 GHz which results in an FP32 computing power of 10.60 TFLOPS.
The INNO3D GeForce RTX 2080 GAMING X2 OC has 2944 shader units and these clock at a maximum of 1.76 GHz and achieve an FP32 computing power of 10.34 TFLOPS. |
||
GPUThe GALAX GeForce RTX 2080 OC White is equipped with a graphics chip of the Turing architecture, which has 46 streaming multiprocessors. The graphics card INNO3D GeForce RTX 2080 GAMING X2 OC is based on the Turing architecture and is equipped with 46 execution units. |
||
| GALAX GeForce RTX 2080 OC White | GPU | INNO3D GeForce RTX 2080 GAMING X2 OC |
| NVIDIA GeForce RTX 2080 | Based on | NVIDIA GeForce RTX 2080 |
| TU104 | GPU Chip | TU104 |
| Turing | Architecture | Turing |
| 46 | Streaming Multiprocessors | 46 |
| 2944 | Shader | 2944 |
| 64 | Render Output Units | 64 |
| 184 | Texture Units | 184 |
| 46 | Raytracing Cores | 46 |
MemoryThe GALAX GeForce RTX 2080 OC White is equipped with a 8 GB large GDDR6 graphics memory, which is equipped with 1.750 GHz clocks. The INNO3D GeForce RTX 2080 GAMING X2 OC has a 8 GB large GDDR6 graphics memory and the memory clock is 1.750GHz. |
||
| 8 GB | Memory Size | 8 GB |
| GDDR6 | Memory Type | GDDR6 |
| 1.750 GHz | Memory Clock | 1.750 GHz |
| 14.0 Gbps | Memory Speed | 14.0 Gbps |
| 448 GB/s | Memory bandwidth | 448 GB/s |
| 256 bit | Memory Interface | 256 bit |
Clock SpeedsThe GALAX GeForce RTX 2080 OC White has a turbo clock of 1.800 GHz  + 5 %. The turbo frequency of the INNO3D GeForce RTX 2080 GAMING X2 OC is 1.755 GHz+ 3 %. |
||
| 1.515 GHz | Base Clock | 1.515 GHz |
| 1.800 GHz+ 5 % |
Boost Clock | 1.755 GHz+ 3 % |
| 1.71 GHz | Avg (Game) Clock | 1.71 GHz |
| Yes | Overclocking | Yes |
Thermal DesignThe GALAX GeForce RTX 2080 OC White has 1 x 6-Pin, 1 x 8-Pin connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as 88 °C. The INNO3D GeForce RTX 2080 GAMING X2 OC is equipped with a 1 x 6-Pin, 1 x 8-Pin PCIe power connector that supplies it with power. The maximum operating temperature of the card is 88 °C. |
||
| 215 W | TDP | 215 W |
| -- | TDP (up) | 250 W+ 5 % |
| 88 °C | Tjunction max | 88 °C |
| 1 x 6-Pin, 1 x 8-Pin | PCIe-Power | 1 x 6-Pin, 1 x 8-Pin |
Cooler & FansThe graphics processor and graphics memory of the GALAX GeForce RTX 2080 OC White are cooled with a Air cooling. The INNO3D GeForce RTX 2080 GAMING X2 OC is cooled by a Air cooling. |
||
| Axial | Fan-Type | Axial |
| 2 x 90 mm | Fan 1 | 2 x 90 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| dB | Noise (Idle) | dB |
| -- | Noise (Load) | -- |
ConnectivityThe GALAX GeForce RTX 2080 OC White supports the downward compatible copy protection HDCP in version 2.2. The INNO3D GeForce RTX 2080 GAMING X2 OC supports HDCP in version 2.2 and all previous versions. |
||
| 4 | Max. Displays | 4 |
| 2.2 | HDCP-Version | 2.2 |
| 1x HDMI v2.0b | HDMI Ports | 1x HDMI v2.0b |
| 3x DP v1.4a | DP Ports | 3x DP v1.4a |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| 1 | USB-C Ports | 1 |
FeaturesetThe GALAX GeForce RTX 2080 OC White supports the DirectX standard from Microsoft in version 12_2 (Ultimate). The INNO3D GeForce RTX 2080 GAMING X2 OC supports Microsoft's DirectX version 12_2 (Ultimate). |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| Addressable LED | LED | ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light |
Supported Video CodecsThis area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| No | AV1 | No |
| Decode | VP8 | Decode |
| Decode | VP9 | Decode |
DimensionsThe GALAX GeForce RTX 2080 OC White is 41 mm wide and therefore needs the space of 2 PCIe-Slots in the case. The width of the INNO3D GeForce RTX 2080 GAMING X2 OC is 41 mm and thus requires the space of 2 PCIe-Slots in the PC case. |
||
| 283 mm | Length | 268 mm |
| 139 mm | Height | 113 mm |
| 41 mm | Width | -- |
| 2 PCIe-Slots | Width (Slots) | 2 PCIe-Slots |
| -- | Weight | -- |
| PCIe 3.0 x 16 | GPU Interface | PCIe 3.0 x 16 |
| No | SFF-Ready | No |
Additional dataManufactured using the 12 nanometer process, GALAX GeForce RTX 2080 OC White was released in Q3/2018. The INNO3D GeForce RTX 2080 GAMING X2 OC published in Q3/2018 is manufactured with a structure width of 12 nanometers. |
||
| 28NSL6UCT6WO | Part-no | N20802-08D6X-1180633 |
| Q3/2018 | Release date | Q3/2018 |
| 699 $ (Reference) | Launch Price | 699 $ (Reference) |
| 12 nm | Structure size | 12 nm |
| data sheet | Documents | data sheet |
1.515 GHz, 8 GB (215 W TDP)
Buy this graphic card at amazon!
1.515 GHz, 8 GB (215 W TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
Port Royal (Raytracing)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
Speed Way Graphics Score (Raytracing)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
3840x2160 (2160p)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
2560x1440 (1440p)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
3840x2160 (2160p)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
2560x1440 (1440p)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
Geekbench 6 - Vulkan
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
GALAX GeForce RTX 2080 OC White
8 GB GDDR6 |
||
|
|
INNO3D GeForce RTX 2080 GAMING X2 OC
8 GB GDDR6 |
||
