MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
vs
AMD Radeon RX 6650 XT
GPU comparison with benchmarksIn the gpu comparison between the MANLI GeForce GTX 1660 Super (F347-1G+N537-10) and the AMD Radeon RX 6650 XT, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe MANLI GeForce GTX 1660 Super (F347-1G+N537-10) is based on the NVIDIA GeForce GTX 1660 SUPER and has 1408 texture shaders and 22 execution units. AMD Radeon RX 6650 XT is based on AMD Radeon RX 6650 XT, which has 2048 shaders and 32 execution units. |
||
| MANLI GeForce GTX 1660 Super (F347-1G+N537-10) | GPU | AMD Radeon RX 6650 XT |
| NVIDIA GeForce GTX 1660 SUPER | Based on | AMD Radeon RX 6650 XT |
| TU116-300-A1 | GPU Chip | Navi 23 KXT |
| Turing | Architecture | RDNA 2 |
| 22 | Streaming Multiprocessors | 32 |
| 1408 | Shader | 2048 |
| 48 | Render Output Units | 64 |
| 88 | Texture Units | 128 |
| 0 | Raytracing Cores | 32 |
MemoryThe MANLI GeForce GTX 1660 Super (F347-1G+N537-10) has 6 GB of graphics memory of the type GDDR6 and achieves a memory bandwidth of 336 GB/s. The AMD Radeon RX 6650 XT can access 8 GB GDDR6 graphics memory and thus achieves a memory bandwidth of 280 GB/s. |
||
| 6 GB | Memory Size | 8 GB |
| GDDR6 | Memory Type | GDDR6 |
| 1.750 GHz | Memory Clock | 2.190 GHz |
| 14.0 Gbps | Memory Speed | 17.5 Gbps |
| 336 GB/s | Memory bandwidth | 280 GB/s |
| 192 bit | Memory Interface | 128 bit |
Clock SpeedsThe MANLI GeForce GTX 1660 Super (F347-1G+N537-10) clocks in the base with up to 1.530 GHz. The base frequency of the AMD Radeon RX 6650 XT is 2.055 GHz. |
||
| 1.530 GHz | Base Clock | 2.055 GHz |
| 1.785 GHz | Boost Clock | 2.635 GHz |
| Avg (Game) Clock | 2.41 GHz | |
| Yes | Overclocking | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the MANLI GeForce GTX 1660 Super (F347-1G+N537-10) is 125 W. The graphics card is supplied with energy via the 1 x 8-Pin connector. The AMD Radeon RX 6650 XT has a TDP of 180 W and is supplied with the required energy via 1 x 8-Pin PCIe power connectors. |
||
| 125 W | TDP | 180 W |
| -- | TDP (up) | -- |
| 93 °C | Tjunction max | 100 °C |
| 1 x 8-Pin | PCIe-Power | 1 x 8-Pin |
Cooler & FansThe MANLI GeForce GTX 1660 Super (F347-1G+N537-10) has a total of 2 Axial fans. The AMD Radeon RX 6650 XT has 0 Axial fans to cool the GPU and memory. |
||
| Axial | Fan-Type | Axial |
| 2 x 80 mm | Fan 1 | -- |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| dB | Noise (Idle) | 0 dB |
| -- | Noise (Load) | -- |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 3 screens can be connected to the MANLI GeForce GTX 1660 Super (F347-1G+N537-10). The AMD Radeon RX 6650 XT supports a maximum of 4 screens. |
||
| 3 | Max. Displays | 4 |
| 2.2 | HDCP-Version | 2.3 |
| 1x HDMI v2.0b | HDMI Ports | 1x HDMI v2.1 |
| 1x DP v1.4 | DP Ports | 3x DP v1.4a |
| 1 | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe MANLI GeForce GTX 1660 Super (F347-1G+N537-10) supports a maximum resolution of 7680x4320 pixels. The maximum resolution of the AMD Radeon RX 6650 XT is 7680x4320 pixels. |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_1 | DirectX | 12_2 (Ultimate) |
| No | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | No LED lighting |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| No | AV1 | Decode |
| Decode | VP8 | Decode / Encode |
| Decode | VP9 | Decode / Encode |
DimensionsThe MANLI GeForce GTX 1660 Super (F347-1G+N537-10) is 232 mm long, 125 mm high and 42 mm wide. The AMD Radeon RX 6650 XT is -- long, -- high and -- wide. |
||
| 232 mm | Length | -- |
| 125 mm | Height | -- |
| 42 mm | Width | -- |
| 2 PCIe-Slots | Width (Slots) | -- |
| -- | Weight | -- |
| PCIe 3.0 x 16 | GPU Interface | PCIe 4.0 x 8 |
| No | SFF-Ready | No |
Additional dataThe MANLI GeForce GTX 1660 Super (F347-1G+N537-10) was released in Q4/2019 at a price of 229 $ (Reference). The AMD Radeon RX 6650 XT was introduced in Q2/2022 at a price of 399 $. |
||
| M-NGTX1660S/6REHDPV2-F347-1G | Part-no | -- |
| Q4/2019 | Release date | Q2/2022 |
| 229 $ (Reference) | Launch Price | 399 $ |
| 12 nm | Structure size | 7 nm |
| data sheet | Documents | data sheet |
1.530 GHz, 6 GB (125 W TDP)
Buy this graphic card at amazon!
2.055 GHz, 8 GB (180 W TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
Port Royal (Raytracing)
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
Speed Way Graphics Score (Raytracing)
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
3840x2160 (2160p)
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
2560x1440 (1440p)
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
The Last of Us Part 1
The Last of Us Part One is a game released by Sony in June 2013 exclusively for the Playstation and released for the PC in early 2023. The benchmark values here were determined at high details.
2560x1440 (1440p)
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
3840x2160 (2160p)
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
2560x1440 (1440p)
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
Geekbench 6 - Vulkan
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
Geekbench 6 - Metal
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
MANLI GeForce GTX 1660 Super (F347-1G+N537-10)
6 GB GDDR6 |
||
|
|
AMD Radeon RX 6650 XT
8 GB GDDR6 |
||
