NVIDIA GeForce RTX 5060 Ti 8GB
vs
Colorful GeForce RTX 5050 Battle AX 8GB-V
GPU comparison with benchmarksThe NVIDIA GeForce RTX 5060 Ti 8GB has 4608 shader units and these clock a maximum of 2.57 GHz which results in an FP32 computing power of 23.70 TFLOPS.
The Colorful GeForce RTX 5050 Battle AX 8GB-V has 2560 shader units and these clock at a maximum of 2.57 GHz and achieve an FP32 computing power of 13.17 TFLOPS. |
||
GPUThe NVIDIA GeForce RTX 5060 Ti 8GB is equipped with a graphics chip of the Blackwell architecture, which has 36 streaming multiprocessors. The graphics card Colorful GeForce RTX 5050 Battle AX 8GB-V is based on the Blackwell 2.0 architecture and is equipped with 20 execution units. |
||
| NVIDIA GeForce RTX 5060 Ti 8GB | GPU | Colorful GeForce RTX 5050 Battle AX 8GB-V |
| NVIDIA GeForce RTX 5060 TI 8GB | Based on | NVIDIA GeForce RTX 5050 |
| GB206 | GPU Chip | GB207-300-A1 |
| Blackwell | Architecture | Blackwell 2.0 |
| 36 | Streaming Multiprocessors | 20 |
| 4608 | Shader | 2560 |
| 48 | Render Output Units | 32 |
| 144 | Texture Units | 80 |
| 36 | Raytracing Cores | 20 |
MemoryThe NVIDIA GeForce RTX 5060 Ti 8GB is equipped with a 8 GB large GDDR7 graphics memory, which is equipped with 1.750 GHz clocks. The Colorful GeForce RTX 5050 Battle AX 8GB-V has a 8 GB large GDDR6 graphics memory and the memory clock is 2.500GHz. |
||
| 8 GB | Memory Size | 8 GB |
| GDDR7 | Memory Type | GDDR6 |
| 1.750 GHz | Memory Clock | 2.500 GHz |
| 28.0 Gbps | Memory Speed | 20.0 Gbps |
| 448 GB/s | Memory bandwidth | 320 GB/s |
| 128 bit | Memory Interface | 128 bit |
Clock SpeedsThe NVIDIA GeForce RTX 5060 Ti 8GB has a turbo clock of 2.572 GHz. The turbo frequency of the Colorful GeForce RTX 5050 Battle AX 8GB-V is 2.572 GHz. |
||
| 2.407 GHz | Base Clock | 2.280 GHz |
| 2.572 GHz | Boost Clock | 2.572 GHz |
| Avg (Game) Clock | ||
| Yes | Overclocking | Yes |
Thermal DesignThe NVIDIA GeForce RTX 5060 Ti 8GB has 1 x 8-Pin connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as 87 °C. The Colorful GeForce RTX 5050 Battle AX 8GB-V is equipped with a 1 x 8-Pin PCIe power connector that supplies it with power. The maximum operating temperature of the card is 85 °C. |
||
| 180 W (Reference) | TDP | 130 W |
| -- | TDP (up) | -- |
| 87 °C | Tjunction max | 85 °C |
| 1 x 8-Pin | PCIe-Power | 1 x 8-Pin |
Cooler & FansThe graphics processor and graphics memory of the NVIDIA GeForce RTX 5060 Ti 8GB are cooled with a Air cooling. The Colorful GeForce RTX 5050 Battle AX 8GB-V is cooled by a Air cooling. |
||
| -- | Fan-Type | Axial |
| -- | Fan 1 | 3 x 90 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| 0 dB | Noise (Idle) | 0 dB |
| -- | Noise (Load) | -- |
ConnectivityThe NVIDIA GeForce RTX 5060 Ti 8GB supports the downward compatible copy protection HDCP in version 2.3. The Colorful GeForce RTX 5050 Battle AX 8GB-V supports HDCP in version 2.3 and all previous versions. |
||
| 4 | Max. Displays | 4 |
| 2.3 | HDCP-Version | 2.3 |
| 1x HDMI v2.1b | HDMI Ports | 1x HDMI v2.1b |
| 3x DP v2.1b | DP Ports | 3x DP v2.1b |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe NVIDIA GeForce RTX 5060 Ti 8GB supports the DirectX standard from Microsoft in version 12_2 (Ultimate). The Colorful GeForce RTX 5050 Battle AX 8GB-V supports Microsoft's DirectX version 12_2 (Ultimate). |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | Non addressable LED |
Supported Video CodecsThis area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode / Encode | AV1 | Decode / Encode |
| Decode / Encode | VP8 | Decode / Encode |
| Decode / Encode | VP9 | Decode / Encode |
DimensionsThe NVIDIA GeForce RTX 5060 Ti 8GB is -- wide and therefore needs the space of 3 PCIe-Slots in the case. The width of the Colorful GeForce RTX 5050 Battle AX 8GB-V is -- and thus requires the space of 3 PCIe-Slots in the PC case. |
||
| -- | Length | 301 mm |
| -- | Height | 120 mm |
| -- | Width | 50 mm |
| -- | Width (Slots) | 3 PCIe-Slots |
| -- | Weight | 800 g |
| PCIe 5 x 8 | GPU Interface | PCIe 5 x 8 |
| No | SFF-Ready | No |
Additional dataManufactured using the 4 nanometer process, NVIDIA GeForce RTX 5060 Ti 8GB was released in Q2/2025. The Colorful GeForce RTX 5050 Battle AX 8GB-V published in Q3/2025 is manufactured with a structure width of 5 nanometers. |
||
| -- | Part-no | -- |
| Q2/2025 | Release date | Q3/2025 |
| 379 $ (Reference) | Launch Price | 249 $ (Reference) |
| 4 nm | Structure size | 5 nm |
| data sheet | Documents | data sheet |
2.407 GHz, 8 GB (-- TDP)
Buy this graphic card at amazon!
2.280 GHz, 8 GB (130 W TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
NVIDIA GeForce RTX 5060 Ti 8GB
8 GB GDDR7 |
||
|
Colorful GeForce RTX 5050 Battle AX 8GB-V
8 GB GDDR6 |
||
