Palit GeForce RTX 3060 StormX
vs
PowerColor Radeon RX 5700 Red Devil
GPU comparison with benchmarksIn the gpu comparison between the Palit GeForce RTX 3060 StormX and the PowerColor Radeon RX 5700 Red Devil, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe Palit GeForce RTX 3060 StormX is based on the NVIDIA GeForce RTX 3060 and has 3584 texture shaders and 28 execution units. PowerColor Radeon RX 5700 Red Devil is based on AMD Radeon RX 5700, which has 2304 shaders and 36 execution units. |
||
| Palit GeForce RTX 3060 StormX | GPU | PowerColor Radeon RX 5700 Red Devil |
| NVIDIA GeForce RTX 3060 | Based on | AMD Radeon RX 5700 |
| GA106-300-A1 | GPU Chip | Navi 10 |
| Ampere | Architecture | RDNA 1 |
| 28 | Streaming Multiprocessors | 36 |
| 3584 | Shader | 2304 |
| 48 | Render Output Units | 64 |
| 112 | Texture Units | 144 |
| 28 | Raytracing Cores | 0 |
MemoryThe Palit GeForce RTX 3060 StormX has 12 GB of graphics memory of the type GDDR6 and achieves a memory bandwidth of 360 GB/s. The PowerColor Radeon RX 5700 Red Devil can access 8 GB GDDR6 graphics memory and thus achieves a memory bandwidth of 448 GB/s. |
||
| 12 GB | Memory Size | 8 GB |
| GDDR6 | Memory Type | GDDR6 |
| 1.875 GHz | Memory Clock | 1.750 GHz |
| 15.0 Gbps | Memory Speed | 14.0 Gbps |
| 360 GB/s | Memory bandwidth | 448 GB/s |
| 192 bit | Memory Interface | 256 bit |
Clock SpeedsThe Palit GeForce RTX 3060 StormX clocks in the base with up to 1.320 GHz. The base frequency of the PowerColor Radeon RX 5700 Red Devil is 1.610 GHz. |
||
| 1.320 GHz | Base Clock | 1.610 GHz |
| 1.777 GHz | Boost Clock | 1.750 GHz |
| Avg (Game) Clock | 1.73 GHz | |
| Yes | Overclocking | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the Palit GeForce RTX 3060 StormX is 170 W. The graphics card is supplied with energy via the 1 x 8-Pin connector. The PowerColor Radeon RX 5700 Red Devil has a TDP of 180 W and is supplied with the required energy via 1 x 6-Pin, 1 x 8-Pin PCIe power connectors. |
||
| 170 W | TDP | 180 W |
| -- | TDP (up) | 220 W |
| 93 °C | Tjunction max | 98 °C |
| 1 x 8-Pin | PCIe-Power | 1 x 6-Pin, 1 x 8-Pin |
Cooler & FansThe Palit GeForce RTX 3060 StormX has a total of 1 Axial fans. The PowerColor Radeon RX 5700 Red Devil has 3 Axial fans to cool the GPU and memory. |
||
| Axial | Fan-Type | Axial |
| 1 x 100 mm | Fan 1 | 3 x 90 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| 0 dB | Noise (Idle) | 0 dB |
| 39 dB | Noise (Load) | 41 dB |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 4 screens can be connected to the Palit GeForce RTX 3060 StormX. The PowerColor Radeon RX 5700 Red Devil supports a maximum of 4 screens. |
||
| 4 | Max. Displays | 4 |
| 2.3 | HDCP-Version | 2.3 |
| 1x HDMI v2.1 | HDMI Ports | 1x HDMI v2.0b |
| 3x DP v1.4a | DP Ports | 3x DP v1.4 |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe Palit GeForce RTX 3060 StormX supports a maximum resolution of 7680x4320 pixels. The maximum resolution of the PowerColor Radeon RX 5700 Red Devil is 7680x4320 pixels. |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | No |
| Yes | DLSS / FSR | Yes |
| Addressable LED | LED | No LED lighting |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode | AV1 | No |
| Decode | VP8 | Decode |
| Decode | VP9 | Decode / Encode |
DimensionsThe Palit GeForce RTX 3060 StormX is 170 mm long, 125 mm high and 39 mm wide. The PowerColor Radeon RX 5700 Red Devil is 300 mm long, 132 mm high and 53 mm wide. |
||
| 170 mm | Length | 300 mm |
| 125 mm | Height | 132 mm |
| 39 mm | Width | 53 mm |
| 2 PCIe-Slots | Width (Slots) | 2 PCIe-Slots |
| -- | Weight | -- |
| PCIe 4.0 x 16 | GPU Interface | PCIe 4.0 x 16 |
| No | SFF-Ready | No |
Additional dataThe Palit GeForce RTX 3060 StormX was released in Q1/2021 at a price of 369 $. The PowerColor Radeon RX 5700 Red Devil was introduced in Q3/2019 at a price of 379 $. |
||
| NE63060019K9-190AF | Part-no | -- |
| Q1/2021 | Release date | Q3/2019 |
| 369 $ | Launch Price | 379 $ |
| 8 nm | Structure size | 7 nm |
| data sheet | Documents | data sheet |
1.320 GHz, 12 GB (170 W TDP)
Buy this graphic card at amazon!
1.610 GHz, 8 GB (180 W TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
Port Royal (Raytracing)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
Speed Way Graphics Score (Raytracing)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
3840x2160 (2160p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
2560x1440 (1440p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
The Last of Us Part 1
The Last of Us Part One is a game released by Sony in June 2013 exclusively for the Playstation and released for the PC in early 2023. The benchmark values here were determined at high details.
3840x2160 (2160p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
2560x1440 (1440p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
3840x2160 (2160p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
2560x1440 (1440p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
1920x1080 (1080p)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
Geekbench 6 - Vulkan
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
Geekbench 6 - Metal
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
Palit GeForce RTX 3060 StormX
12 GB GDDR6 |
||
|
|
PowerColor Radeon RX 5700 Red Devil
8 GB GDDR6 |
||
