Palit GeForce RTX 4070 SUPER Dual OC
vs
Manli Nebula GeForce RTX 5070
GPU comparison with benchmarksIn the gpu comparison between the Palit GeForce RTX 4070 SUPER Dual OC and the Manli Nebula GeForce RTX 5070, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe Palit GeForce RTX 4070 SUPER Dual OC is based on the NVIDIA GeForce RTX 4070 SUPER and has 7168 texture shaders and 56 execution units. Manli Nebula GeForce RTX 5070 is based on NVIDIA GeForce RTX 5070, which has 6144 shaders and 48 execution units. |
||
| Palit GeForce RTX 4070 SUPER Dual OC | GPU | Manli Nebula GeForce RTX 5070 |
| NVIDIA GeForce RTX 4070 SUPER | Based on | NVIDIA GeForce RTX 5070 |
| AD104-350-A1 | GPU Chip | GB205-300-A1 |
| Ada Lovelace | Architecture | Blackwell |
| 56 | Streaming Multiprocessors | 48 |
| 7168 | Shader | 6144 |
| 80 | Render Output Units | 64 |
| 224 | Texture Units | 192 |
| 56 | Raytracing Cores | 48 |
MemoryThe Palit GeForce RTX 4070 SUPER Dual OC has 12 GB of graphics memory of the type GDDR6X and achieves a memory bandwidth of 504 GB/s. The Manli Nebula GeForce RTX 5070 can access 12 GB GDDR7 graphics memory and thus achieves a memory bandwidth of 672 GB/s. |
||
| 12 GB | Memory Size | 12 GB |
| GDDR6X | Memory Type | GDDR7 |
| 1.313 GHz | Memory Clock | 1.750 GHz |
| 21.0 Gbps | Memory Speed | 28.0 Gbps |
| 504 GB/s | Memory bandwidth | 672 GB/s |
| 192 bit | Memory Interface | 192 bit |
Clock SpeedsThe Palit GeForce RTX 4070 SUPER Dual OC clocks in the base with up to 1.980 GHz. The base frequency of the Manli Nebula GeForce RTX 5070 is 2.165 GHz. |
||
| 1.980 GHz | Base Clock | 2.165 GHz |
| 2.550 GHz | Boost Clock | 2.512 GHz |
| Avg (Game) Clock | ||
| Yes | Overclocking | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the Palit GeForce RTX 4070 SUPER Dual OC is 220 W. The graphics card is supplied with energy via the 1 x 16-Pin connector. The Manli Nebula GeForce RTX 5070 has a TDP of 250 W (Reference) and is supplied with the required energy via 1 x 16-Pin PCIe power connectors. |
||
| 220 W | TDP | 250 W (Reference) |
| -- | TDP (up) | -- |
| 90 °C | Tjunction max | 85 °C |
| 1 x 16-Pin | PCIe-Power | 1 x 16-Pin |
Cooler & FansThe Palit GeForce RTX 4070 SUPER Dual OC has a total of 2 Axial fans. The Manli Nebula GeForce RTX 5070 has 3 Axial fans to cool the GPU and memory. |
||
| Axial | Fan-Type | Axial |
| 2 x 100 mm | Fan 1 | 3 x 90 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| 0 dB | Noise (Idle) | 0 dB |
| -- | Noise (Load) | -- |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 4 screens can be connected to the Palit GeForce RTX 4070 SUPER Dual OC. The Manli Nebula GeForce RTX 5070 supports a maximum of 4 screens. |
||
| 4 | Max. Displays | 4 |
| 2.3 | HDCP-Version | 2.3 |
| 1x HDMI v2.1 | HDMI Ports | 1x HDMI v2.1b |
| 3x DP v1.4a | DP Ports | 3x DP v2.1b |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe Palit GeForce RTX 4070 SUPER Dual OC supports a maximum resolution of 7680x4320 pixels. The maximum resolution of the Manli Nebula GeForce RTX 5070 is 7680x4320 pixels. |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| Addressable LED | LED | Addressable LED |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode | AV1 | Decode / Encode |
| Decode | VP8 | Decode / Encode |
| Decode | VP9 | Decode / Encode |
DimensionsThe Palit GeForce RTX 4070 SUPER Dual OC is 269 mm long, 128 mm high and 40 mm wide. The Manli Nebula GeForce RTX 5070 is 312 mm long, 124 mm high and 51 mm wide. |
||
| 269 mm | Length | 312 mm |
| 128 mm | Height | 124 mm |
| 40 mm | Width | 51 mm |
| 2 PCIe-Slots | Width (Slots) | 3 PCIe-Slots |
| -- | Weight | -- |
| PCIe 4.0 x 16 | GPU Interface | PCIe 5 x 16 |
| Yes | SFF-Ready | No |
Additional dataThe Palit GeForce RTX 4070 SUPER Dual OC was released in Q1/2024 at a price of 599 $ (Reference). The Manli Nebula GeForce RTX 5070 was introduced in Q2/2025 at a price of 549 $ (Reference). |
||
| NED407SS19K9-1043D | Part-no | M-N507N/D712G-M3634 |
| Q1/2024 | Release date | Q2/2025 |
| 599 $ (Reference) | Launch Price | 549 $ (Reference) |
| 5 nm | Structure size | 5 nm |
| data sheet | Documents | data sheet |
1.980 GHz, 12 GB (220 W TDP)
Buy this graphic card at amazon!
2.165 GHz, 12 GB (-- TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
|
Manli Nebula GeForce RTX 5070
12 GB GDDR7 |
||
Steel Nomad Light Graphics score
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
|
|
Manli Nebula GeForce RTX 5070
12 GB GDDR7 |
||
Steel Nomad Graphics score
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
|
|
Manli Nebula GeForce RTX 5070
12 GB GDDR7 |
||
Port Royal (Raytracing)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
|
|
Manli Nebula GeForce RTX 5070
12 GB GDDR7 |
||
Speed Way Graphics Score (Raytracing)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
|
|
Manli Nebula GeForce RTX 5070
12 GB GDDR7 |
||
Solar Bay (Raytracing)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
|
|
Manli Nebula GeForce RTX 5070
12 GB GDDR7 |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
3840x2160 (2160p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
2560x1440 (1440p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
1920x1080 (1080p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
The Last of Us Part 1
The Last of Us Part One is a game released by Sony in June 2013 exclusively for the Playstation and released for the PC in early 2023. The benchmark values here were determined at high details.
3840x2160 (2160p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
2560x1440 (1440p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
1920x1080 (1080p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
3840x2160 (2160p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
2560x1440 (1440p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
1920x1080 (1080p)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
Geekbench 6 - Vulkan
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
Palit GeForce RTX 4070 SUPER Dual OC
12 GB GDDR6X |
||
|
|
Manli Nebula GeForce RTX 5070
12 GB GDDR7 |
||
