The INNO3D GeForce RTX 5080 ICHILL FROSTBITE is based on the NVIDIA GeForce RTX 5080 (Blackwell) and has 16 GB GDDR7 graphics memory with a bandwidth of 960 GB/s.
Quick comparison
In FP32 performance, the INNO3D GeForce RTX 5080 ICHILL FROSTBITE is 848 % faster than the INNO3D GeForce GTX 980 Ti.
The INNO3D GeForce GTX 980 Ti has the GM200-310-A1 graphics chip installed, which is based on the Maxwell 2.0 architecture.
The INNO3D GeForce RTX 5080 ICHILL FROSTBITE is based on the graphics chip GB203-400-A1, which comes from the Blackwell architecture.
Memory
Memory
INNO3D GeForce GTX 980 Ti
INNO3D GeForce RTX 5080 ICHILL FROSTBITE
Memory Size
6 GB
16 GB
Memory Type
GDDR5
GDDR7
Memory Clock
1.753 GHz
1.875 GHz
Memory Speed
7.0 Gbps
30.0 Gbps
Memory bandwidth
337 GB/s
960 GB/s
Memory Interface
384 bit
256 bit
More information
The graphics memory of the INNO3D GeForce GTX 980 Ti clocks at 1.753 GHz, which corresponds to a speed of 7.0 Gbps.
The graphics memory speed of the INNO3D GeForce RTX 5080 ICHILL FROSTBITE is 30.0 Gbps and the clock speed is 1.875 GHz.
Clock Speeds
Clock Speeds
INNO3D GeForce GTX 980 Ti
INNO3D GeForce RTX 5080 ICHILL FROSTBITE
Base Clock
1.000 GHz
2.295 GHz
Boost Clock
1.076 GHz
2.670 GHz
Overclocking
Yes
Yes
More information
The clock frequency of a graphics card determines the speed in connection with the graphics architecture.
Thermal Design
Thermal Design
INNO3D GeForce GTX 980 Ti
INNO3D GeForce RTX 5080 ICHILL FROSTBITE
TDP
250 W
360 W
Tjunction max
91 °C
88 °C
PCIe-Power
1 x 6-Pin, 1 x 8-Pin
1 x 16-Pin
More information
The INNO3D GeForce GTX 980 Ti is powered by 1 x 6-Pin, 1 x 8-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 250 W.
The INNO3D GeForce RTX 5080 ICHILL FROSTBITE has 1 x 16-Pin PCIe power connectors that supply it with energy. The manufacturer specifies the TDP of the card as 360 W.
Cooler & Fans
Cooler & Fans
INNO3D GeForce GTX 980 Ti
INNO3D GeForce RTX 5080 ICHILL FROSTBITE
Fan-Type
Radial
--
Fan 1
1 x 65 mm
--
Cooler-Type
Air cooling
Water cooling
Noise (Idle)
0 dB
0 dB
More information
The INNO3D GeForce GTX 980 Ti is equipped with a total of 1 Radial main fans.
The INNO3D GeForce RTX 5080 ICHILL FROSTBITE has 0 -- main fans that cool the GPU and memory.
Connectivity
Connectivity
INNO3D GeForce GTX 980 Ti
INNO3D GeForce RTX 5080 ICHILL FROSTBITE
Max. Displays
4
4
HDCP
2.2
2.3
HDMI
1x HDMI 2.0
1x HDMI 2.1b
DisplayPort
3x DP 1.2
3x DP 2.1b
DVI
1
--
More information
Up to 4 screens can be operated with the INNO3D GeForce GTX 980 Ti.
The INNO3D GeForce RTX 5080 ICHILL FROSTBITE supports the operation of a maximum of 4 monitors.
Featureset
Featureset
INNO3D GeForce GTX 980 Ti
INNO3D GeForce RTX 5080 ICHILL FROSTBITE
Max. resolution
4096x2160
7680x4320
DirectX
12_1
12_2 (Ultimate)
Raytracing
No
Yes
DLSS / FSR
No
Yes
LED
No LED lighting
Addressable LED
More information
With the INNO3D GeForce GTX 980 Ti it is possible to operate a screen with a maximum resolution of up to 4096x2160 pixels.
The maximum supported resolution of the INNO3D GeForce RTX 5080 ICHILL FROSTBITE is 7680x4320 pixels.
Supported Video Codecs
Supported Video Codecs
INNO3D GeForce GTX 980 Ti
INNO3D GeForce RTX 5080 ICHILL FROSTBITE
h264
Decode / Encode
Decode / Encode
h265 / HEVC
No
Decode / Encode
VP8
Decode
Decode / Encode
VP9
No
Decode / Encode
AV1
No
Decode / Encode
More information
The support and acceleration of certain video codecs can have a positive impact on the lower energy consumption and less waste heat from the graphics card.
Dimensions
Dimensions
INNO3D GeForce GTX 980 Ti
INNO3D GeForce RTX 5080 ICHILL FROSTBITE
Length
267 mm
160 mm
Height
111 mm
140 mm
Width
38 mm
31 mm
Width (Slots)
2 Slots
2 Slots
SFF-Ready
No
No
More information
The INNO3D GeForce GTX 980 Ti is connected to the system via PCIe 3 x 16 lanes and requires 2 PCIe-Slots space in the housing.
The INNO3D GeForce RTX 5080 ICHILL FROSTBITE needs the space of 2 PCIe-Slots in the case and has a PCIe 5 x 16 Lanes interface.
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
