The NVIDIA GeForce RTX 3080 Founders Edition (LHR) has 8704 shader units and these clock at a maximum of 1.71 GHz and achieve an FP32 computing power of 29.77 TFLOPS.
Quick comparison
In FP32 performance, the NVIDIA GeForce RTX 3080 Founders Edition (LHR) is 97 % faster than the NVIDIA GeForce RTX 4060.
The NVIDIA GeForce RTX 4060 is equipped with a graphics chip of the Ada Lovelace architecture, which has 24 streaming multiprocessors.
The graphics card NVIDIA GeForce RTX 3080 Founders Edition (LHR) is based on the Ampere architecture and is equipped with 68 execution units.
Memory
Memory
NVIDIA GeForce RTX 4060
NVIDIA GeForce RTX 3080 Founders Edition (LHR)
Memory Size
8 GB
10 GB
Memory Type
GDDR6
GDDR6X
Memory Clock
2.125 GHz
1.188 GHz
Memory Speed
17.0 Gbps
19.0 Gbps
Memory bandwidth
272 GB/s
760 GB/s
Memory Interface
128 bit
320 bit
More information
The NVIDIA GeForce RTX 4060 is equipped with a 8 GB large GDDR6 graphics memory, which is equipped with 2.125 GHz clocks.
The NVIDIA GeForce RTX 3080 Founders Edition (LHR) has a 10 GB large GDDR6X graphics memory and the memory clock is 1.188GHz.
Clock Speeds
Clock Speeds
NVIDIA GeForce RTX 4060
NVIDIA GeForce RTX 3080 Founders Edition (LHR)
Base Clock
1.830 GHz
1.440 GHz
Boost Clock
2.460 GHz
1.710 GHz
Overclocking
Yes
Yes
More information
The NVIDIA GeForce RTX 4060 has a turbo clock of 2.460 GHz. The turbo frequency of the NVIDIA GeForce RTX 3080 Founders Edition (LHR) is 1.710 GHz.
Thermal Design
Thermal Design
NVIDIA GeForce RTX 4060
NVIDIA GeForce RTX 3080 Founders Edition (LHR)
TDP
115 W
320 W
TDP (up)
--
370 W
Tjunction max
90 °C
93 °C
PCIe-Power
1 x 12-Pin
2 x 8-Pin
More information
The NVIDIA GeForce RTX 4060 has 1 x 12-Pin connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as 90 °C.
The NVIDIA GeForce RTX 3080 Founders Edition (LHR) is equipped with a 2 x 8-Pin PCIe power connector that supplies it with power. The maximum operating temperature of the card is 93 °C.
Cooler & Fans
Cooler & Fans
NVIDIA GeForce RTX 4060
NVIDIA GeForce RTX 3080 Founders Edition (LHR)
Fan-Type
--
Axial
Fan 1
--
2 x 85 mm
Cooler-Type
Air cooling
Air cooling
Noise (Idle)
0 dB
0 dB
Noise (Load)
--
43 dB
More information
The graphics processor and graphics memory of the NVIDIA GeForce RTX 4060 are cooled with a Air cooling.
The NVIDIA GeForce RTX 3080 Founders Edition (LHR) is cooled by a Air cooling.
Connectivity
Connectivity
NVIDIA GeForce RTX 4060
NVIDIA GeForce RTX 3080 Founders Edition (LHR)
Max. Displays
4
4
HDCP
2.3
2.3
HDMI
1x HDMI 2.1a
1x HDMI 2.1
DisplayPort
3x DP 1.4a
3x DP 1.4a
More information
The NVIDIA GeForce RTX 4060 supports the downward compatible copy protection HDCP in version 2.3.
The NVIDIA GeForce RTX 3080 Founders Edition (LHR) supports HDCP in version 2.3 and all previous versions.
Featureset
Featureset
NVIDIA GeForce RTX 4060
NVIDIA GeForce RTX 3080 Founders Edition (LHR)
Max. resolution
7680x4320
7680x4320
DirectX
12_2 (Ultimate)
12_2 (Ultimate)
Raytracing
Yes
Yes
DLSS / FSR
Yes
Yes
LED
No LED lighting
No LED lighting
More information
The NVIDIA GeForce RTX 4060 supports the DirectX standard from Microsoft in version 12_2 (Ultimate).
The NVIDIA GeForce RTX 3080 Founders Edition (LHR) supports Microsoft's DirectX version 12_2 (Ultimate).
Supported Video Codecs
Supported Video Codecs
NVIDIA GeForce RTX 4060
NVIDIA GeForce RTX 3080 Founders Edition (LHR)
h264
Decode / Encode
Decode / Encode
h265 / HEVC
Decode / Encode
Decode / Encode
VP8
Decode
Decode
VP9
Decode
Decode
AV1
Decode / Encode
Decode
More information
This area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load.
Dimensions
Dimensions
NVIDIA GeForce RTX 4060
NVIDIA GeForce RTX 3080 Founders Edition (LHR)
Length
--
285 mm
Height
--
110 mm
Width (Slots)
--
2 Slots
Weight
--
1,350 g
SFF-Ready
No
No
More information
The NVIDIA GeForce RTX 4060 is -- wide and therefore needs the space of 2 PCIe-Slots in the case.
The width of the NVIDIA GeForce RTX 3080 Founders Edition (LHR) is -- and thus requires the space of 2 PCIe-Slots in the PC case.
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
The Last of Us Part One is a game released by Sony in June 2013 exclusively for the Playstation and released for the PC in early 2023. The benchmark values here were determined at high details.
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
