NVIDIA GeForce RTX 4070 Ti
vs
Apple M1 Max 24-Core GPU
GPU comparison with benchmarksIn the gpu comparison between the NVIDIA GeForce RTX 4070 Ti and the Apple M1 Max 24-Core GPU, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe NVIDIA GeForce RTX 4070 Ti is based on the NVIDIA GeForce RTX 4070 Ti and has 7680 texture shaders and 60 execution units. Apple M1 Max 24-Core GPU is based on Apple M1 Max (24-GPU), which has 3072 shaders and 384 execution units. |
||
| NVIDIA GeForce RTX 4070 Ti | GPU | Apple M1 Max 24-Core GPU |
| NVIDIA GeForce RTX 4070 Ti | Based on | Apple M1 Max (24-GPU) |
| AD104-400-A1 | GPU Chip | M1 Max |
| Ada Lovelace | Architecture | M1 |
| 60 | Streaming Multiprocessors | 384 |
| 7680 | Shader | 3072 |
| 80 | Render Output Units | 0 |
| 240 | Texture Units | 0 |
| 60 | Raytracing Cores | 0 |
MemoryThe NVIDIA GeForce RTX 4070 Ti has 12 GB of graphics memory of the type GDDR6X and achieves a memory bandwidth of 504 GB/s. The Apple M1 Max 24-Core GPU can access 32 GB LPDDR5 graphics memory and thus achieves a memory bandwidth of 410 GB/s. |
||
| 12 GB | Memory Size | 32 GB |
| GDDR6X | Memory Type | LPDDR5 |
| 1.313 GHz | Memory Clock | 3.200 GHz |
| 21.0 Gbps | Memory Speed | 0.0 Gbps |
| 504 GB/s | Memory bandwidth | 410 GB/s |
| 192 bit | Memory Interface | 512 bit |
Clock SpeedsThe NVIDIA GeForce RTX 4070 Ti clocks in the base with up to 2.310 GHz. The base frequency of the Apple M1 Max 24-Core GPU is 1.300 GHz. |
||
| 2.310 GHz | Base Clock | 1.300 GHz |
| 2.610 GHz | Boost Clock | |
| Avg (Game) Clock | ||
| Yes | Overclocking | No |
Thermal DesignThe TDP (Thermal Design Power) of the NVIDIA GeForce RTX 4070 Ti is 285 W. The graphics card is supplied with energy via the 1 x 16-Pin connector. The Apple M1 Max 24-Core GPU has a TDP of -- and is supplied with the required energy via PCIe power connectors. |
||
| 285 W | TDP | -- |
| -- | TDP (up) | -- |
| 90 °C | Tjunction max | Unknown |
| 1 x 16-Pin | PCIe-Power | |
Cooler & FansThe NVIDIA GeForce RTX 4070 Ti has a total of 0 -- fans. The Apple M1 Max 24-Core GPU has 0 -- fans to cool the GPU and memory. |
||
| -- | Fan-Type | -- |
| -- | Fan 1 | -- |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| dB | Noise (Idle) | -- |
| -- | Noise (Load) | -- |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 4 screens can be connected to the NVIDIA GeForce RTX 4070 Ti. The Apple M1 Max 24-Core GPU supports a maximum of 5 screens. |
||
| 4 | Max. Displays | 5 |
| 2.3 | HDCP-Version | -- |
| 1x HDMI v2.1 | HDMI Ports | -- |
| 3x DP v1.4a | DP Ports | -- |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe NVIDIA GeForce RTX 4070 Ti supports a maximum resolution of 7680x4320 pixels. The maximum resolution of the Apple M1 Max 24-Core GPU is 6016x3384 pixels. |
||
| 7680x4320 | Max. resolution | 6016x3384 |
| 12_2 (Ultimate) | DirectX | 0 |
| Yes | Raytracing | No |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | No LED lighting |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode | AV1 | No |
| Decode | VP8 | Decode |
| Decode | VP9 | Decode / Encode |
DimensionsThe NVIDIA GeForce RTX 4070 Ti is -- long, -- high and -- wide. The Apple M1 Max 24-Core GPU is -- long, -- high and -- wide. |
||
| -- | Length | -- |
| -- | Height | -- |
| -- | Width | -- |
| -- | Width (Slots) | -- |
| -- | Weight | -- |
| PCIe 4.0 x 16 | GPU Interface | Integrated graphics |
| No | SFF-Ready | No |
Additional dataThe NVIDIA GeForce RTX 4070 Ti was released in Q1/2023 at a price of 799 $. The Apple M1 Max 24-Core GPU was introduced in Q3/2021 at a price of --. |
||
| -- | Part-no | -- |
| Q1/2023 | Release date | Q3/2021 |
| 799 $ | Launch Price | -- |
| 5 nm | Structure size | 5 nm |
| data sheet | Documents | -- |
2.310 GHz, 12 GB (285 W TDP)
Buy this graphic card at amazon!
1.300 GHz, 32 GB (-- TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Steel Nomad Light Graphics score
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Steel Nomad Graphics score
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Port Royal (Raytracing)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Speed Way Graphics Score (Raytracing)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Solar Bay (Raytracing)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
3840x2160 (2160p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
2560x1440 (1440p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
1920x1080 (1080p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
The Last of Us Part 1
The Last of Us Part One is a game released by Sony in June 2013 exclusively for the Playstation and released for the PC in early 2023. The benchmark values here were determined at high details.
3840x2160 (2160p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
2560x1440 (1440p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
1920x1080 (1080p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
3840x2160 (2160p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
2560x1440 (1440p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
1920x1080 (1080p)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
|
Apple M1 Max 24-Core GPU
32 GB LPDDR5 |
||
Geekbench 6 - Vulkan
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
Geekbench 6 - Metal
|
|
Apple M1 Max 24-Core GPU
32 GB LPDDR5 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
NVIDIA GeForce RTX 4070 Ti
12 GB GDDR6X |
||
|
|
Apple M1 Max 24-Core GPU
32 GB LPDDR5 |
||
