GPU comparison with benchmarksIn the gpu comparison between the XFX Radeon RX Vega 64 Black Fan and the Gainward GeForce RTX 2070 Phantom, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe XFX Radeon RX Vega 64 Black Fan is based on the AMD RX Vega 64 and has 4096 texture shaders and 64 execution units. Gainward GeForce RTX 2070 Phantom is based on NVIDIA GeForce RTX 2070, which has 2304 shaders and 36 execution units. |
||
XFX Radeon RX Vega 64 Black Fan | GPU | Gainward GeForce RTX 2070 Phantom |
AMD RX Vega 64 | Based on | NVIDIA GeForce RTX 2070 |
Vega 10 XT | GPU Chip | TU106 |
GCN 5 | Architecture | Turing |
64 | Streaming Multiprocessors | 36 |
4096 | Shader | 2304 |
64 | Render Output Units | 64 |
256 | Texture Units | 144 |
0 | Raytracing Cores | 36 |
MemoryThe XFX Radeon RX Vega 64 Black Fan has 8 GB of graphics memory of the type HBM2 and achieves a memory bandwidth of 484 GB/s. The Gainward GeForce RTX 2070 Phantom can access 8 GB GDDR6 graphics memory and thus achieves a memory bandwidth of 448 GB/s. |
||
8 GB | Memory Size | 8 GB |
HBM2 | Memory Type | GDDR6 |
0.945 GHz | Memory Clock | 1.750 GHz |
1.9 Gbps | Memory Speed | 14.0 Gbps |
484 GB/s | Memory bandwidth | 448 GB/s |
2048 bit | Memory Interface | 256 bit |
Clock SpeedsThe XFX Radeon RX Vega 64 Black Fan clocks in the base with up to 1.247 GHz. The base frequency of the Gainward GeForce RTX 2070 Phantom is 1.410 GHz. |
||
1.247 GHz | Base Clock | 1.410 GHz |
1.546 GHz | Boost Clock | 1.620 GHz |
Avg (Game) Clock | ||
Yes | Overclocking | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the XFX Radeon RX Vega 64 Black Fan is 295 W. The graphics card is supplied with energy via the 2 x 8-Pin connector. The Gainward GeForce RTX 2070 Phantom has a TDP of 175 W and is supplied with the required energy via 1 x 6-Pin, 1 x 8-Pin PCIe power connectors. |
||
295 W | TDP | 175 W |
-- | TDP (up) | -- |
100 °C | Tjunction max | 89 °C |
2 x 8-Pin | PCIe-Power | 1 x 6-Pin, 1 x 8-Pin |
Cooler & FansThe XFX Radeon RX Vega 64 Black Fan has a total of 1 Radial fans. The Gainward GeForce RTX 2070 Phantom has 3 Axial fans to cool the GPU and memory. |
||
Radial | Fan-Type | Axial |
1 x 70 mm | Fan 1 | 3 x 90 mm |
-- | Fan 2 | -- |
Air cooling | Cooler-Type | Air cooling |
dB | Noise (Idle) | 0 dB |
-- | Noise (Load) | -- |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 4 screens can be connected to the XFX Radeon RX Vega 64 Black Fan. The Gainward GeForce RTX 2070 Phantom supports a maximum of 4 screens. |
||
4 | Max. Displays | 4 |
2.2 | HDCP-Version | 2.2 |
1x HDMI v2.0b | HDMI Ports | 1x HDMI v2.0b |
3x DP v1.4 | DP Ports | 3x DP v1.4a |
-- | DVI Ports | -- |
-- | VGA Ports | -- |
-- | USB-C Ports | 1 |
FeaturesetThe XFX Radeon RX Vega 64 Black Fan supports a maximum resolution of 7680x4320 pixels. The maximum resolution of the Gainward GeForce RTX 2070 Phantom is 7680x4320 pixels. |
||
7680x4320 | Max. resolution | 7680x4320 |
12_1 | DirectX | 12_2 (Ultimate) |
No | Raytracing | Yes |
Yes | DLSS / FSR | Yes |
No LED lighting | LED | No LED lighting |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
Decode / Encode | h264 | Decode / Encode |
Decode / Encode | h265 / HEVC | Decode / Encode |
No | AV1 | No |
Decode | VP8 | Decode |
Decode / Encode | VP9 | Decode |
DimensionsThe XFX Radeon RX Vega 64 Black Fan is 280 mm long, 127 mm high and 40 mm wide. The Gainward GeForce RTX 2070 Phantom is 292 mm long, 130 mm high and 60 mm wide. |
||
280 mm | Length | 292 mm |
127 mm | Height | 130 mm |
40 mm | Width | 60 mm |
2 PCIe-Slots | Width (Slots) | 3 PCIe-Slots |
-- | Weight | -- |
PCIe 3.0 x 16 | GPU Interface | PCIe 3.0 x 16 |
Additional dataThe XFX Radeon RX Vega 64 Black Fan was released in Q3/2017 at a price of 499 $ (Reference). The Gainward GeForce RTX 2070 Phantom was introduced in Q4/2018 at a price of 499 $ (Reference). |
||
RX-VEGMTBFX6 | Part-no | 426018336-4238 |
Q3/2017 | Release date | Q4/2018 |
499 $ (Reference) | Launch Price | 499 $ (Reference) |
14 nm | Structure size | 12 nm |
-- | Documents | data sheet |
