EVGA GeForce GTX 1660 XC ULTRA GAMING Benchmark and Specs

The EVGA GeForce GTX 1660 XC ULTRA GAMING has 22 execution units with 1408 shaders. This gives the graphics card a theoretical FP32 computing power of 5.20 TFLOPS.

Based on

NVIDIA GeForce GTX 1660

GPU Chip

TU116-300-A1 (Turing)

Streaming Multiprocessors

22

Shader

1408

Render Output Units

48

Texture Units

88

The EVGA GeForce GTX 1660 XC ULTRA GAMING is equipped with 6 GB graphics memory of the type GDDR5. The memory clock of the graphics card is 2.000 GHz and the speed is 8 Gbps.

Memory Size

6 GB

Memory Type

GDDR5

Memory Clock

2.000 GHz

Memory Speed

8.0 Gbps

Memory bandwidth

192 GB/s

Memory Interface

192 bit

The base frequency of this graphics card is 1.530 GHz and the manufacturer specifies the maximum turbo clock as 1.845 GHz. If supported (see below), the performance can be further increased by overclocking.

Base Clock

1.530 GHz

Boost Clock

1.845 GHz+3 %

Avg (Game) Clock

1.785 GHz

Overclocking

Yes

The EVGA GeForce GTX 1660 XC ULTRA GAMING is powered by 1 x 8-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 120 W.

TDP

120 W

Tjunction max

95 °C

PCIe-Power

1 x 8-Pin

Graphics processor and graphics memory of the EVGA GeForce GTX 1660 XC ULTRA GAMING are cooled by a Air cooling.

Fan-Type

Axial

Fan 1

2 x 90 mm

Cooler-Type

Air cooling

Up to 3 monitors can be operated with the EVGA GeForce GTX 1660 XC ULTRA GAMING.

Max. Displays

3

HDCP

2.2

HDMI

1x HDMI 2.0b

DisplayPort

1x DP 1.4

DVI

1

With the EVGA GeForce GTX 1660 XC ULTRA GAMING it is possible to operate a screen with a resolution of up to 7680x4320 pixels. Furthermore, the DirectX standard version 12_1 is supported.

Max. resolution

7680x4320

DirectX

12_1

Raytracing

No

DLSS / FSR

Yes

LED

No LED lighting

This area lists the video codecs that the EVGA GeForce GTX 1660 XC ULTRA GAMING can decode or encode in hardware in order to minimize the processor load, which leads to lower power consumption.

h264

Decode / Encode

h265 / HEVC

Decode / Encode

VP8

Decode

VP9

Decode

AV1

No

The EVGA GeForce GTX 1660 XC ULTRA GAMING needs the space of 2 PCIe-Slots in a case. It is 268 mm long, 111 mm high and -- wide.

Length

268 mm

Height

111 mm

Width (Slots)

2 PCIe-Slots

SFF-Ready

No

The EVGA GeForce GTX 1660 XC ULTRA GAMING was released in Q1/2019 at a price of 219 $. The graphics card manufactured in 12 nm is connected to the system via PCIe 3.0 x 16 lanes.

GPU Interface

PCIe 3.0 x 16

Release date

Q1/2019

Launch Price

219 $ (Reference)

Structure size

12 nm

Part-no

06G-P4-1167-KR

Documents

data sheet
