The GALAX GeForce GTX 960 Reference Design OC is equipped with 8 execution and 1024 shader units. With single precision, a theoretical FP32 computing power of 2.49 TFLOPS is achieved.
The GALAX GeForce GTX 960 Reference Design OC has a 128 bit wide memory interface, with which a memory bandwidth of 112 GB/s is achieved. In total, 4 GB GDDR5 graphics memory is available for the graphics card.
The manufacturer specifies the memory clock of the GALAX GeForce GTX 960 Reference Design OC with 1.152 GHz (base clock) or with 1.216 GHz (turbo clock). If overclocking is supported (see below), the clock rate can be increased even further.
The GALAX GeForce GTX 960 Reference Design OC has 1 x 6-Pin plugs, which supply the graphics card with energy. The maximum operating temperature of the card is 98 °C.
The GALAX GeForce GTX 960 Reference Design OC is equipped with 1 Radial main fans, which are used to cool the graphics processor and graphics memory.
Up to 4 screens can be connected to the GALAX GeForce GTX 960 Reference Design OC, whereby the backward-compatible HDCP copy protection is supported in the 2.2 version.
The GALAX GeForce GTX 960 Reference Design OC supports a maximum resolution of 4096x2160 pixels and the DirectX standard version 12_1.
Here is a list of which video codecs can be decoded / encoded by the GALAX GeForce GTX 960 Reference Design OC in hardware in order to minimize the processor load.
The dimensions of the GALAX GeForce GTX 960 Reference Design OC are 255 mm in length, 124 mm in height and 41 mm in width. Thus 2 PCIe-Slots are needed in a case.
The GALAX GeForce GTX 960 Reference Design OC is manufactured in a structure width of 28 nm and has a PCIe 3 x 16 lanes interface. The graphics card was released in Q3/2015.
GALAX GeForce GTX 960 Reference Design OCType a model name – the comparison opens automatically.
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
More benchmarks for the graphics card GALAX GeForce GTX 960 Reference Design OC
