The GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 is equipped with 34 execution and 2176 shader units. With single precision, a theoretical FP32 computing power of 7.25 TFLOPS is achieved.
- GPU Chip
- TU106 (Turing)
- Streaming Multiprocessors
- 34
- Shader
- 2176
- Render Output Units
- 64
- Texture Units
- 136
- Raytracing Cores
- 34
The GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 has a 256 bit wide memory interface, with which a memory bandwidth of 448 GB/s is achieved. In total, 8 GB GDDR6 graphics memory is available for the graphics card.
- Memory Size
- 8 GB
- Memory Type
- GDDR6
- Memory Clock
- 1.750 GHz
- Memory Speed
- 14.0 Gbps
- Memory bandwidth
- 448 GB/s
- Memory Interface
- 256 bit
The manufacturer specifies the memory clock of the GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 with 1.470 GHz (base clock) or with 1.665 GHz (turbo clock). If overclocking is supported (see below), the clock rate can be increased even further.
- Base Clock
- 1.470 GHz
- Boost Clock
- 1.665 GHz+1 %
- Avg (Game) Clock
- 1.650 GHz
- Overclocking
- Yes
The GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 has 1 x 6-Pin, 1 x 8-Pin plugs, which supply the graphics card with energy. The maximum operating temperature of the card is 89 °C.
- TDP
- 175 W
- Tjunction max
- 89 °C
- PCIe-Power
- 1 x 6-Pin, 1 x 8-Pin
The GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 is equipped with 2 Axial main fans, which are used to cool the graphics processor and graphics memory.
- Fan-Type
- Axial
- Fan 1
- 2 x 100 mm
- Cooler-Type
- Air cooling
- Noise (Idle)
- 0 dB / Silent
Up to 4 screens can be connected to the GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2, whereby the backward-compatible HDCP copy protection is supported in the 2.2 version.
- Max. Displays
- 4
- HDCP
- 2.2
- HDMI
- 1x HDMI 2.0b
- DisplayPort
- 2x DP 1.4a
The GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 supports a maximum resolution of 7680x4320 pixels and the DirectX standard version 12_2 (Ultimate).
- Max. resolution
- 7680x4320
- DirectX
- 12_2 (Ultimate)
- Raytracing
- Yes
- DLSS / FSR
- Yes
- LED
- Addressable LED
Here is a list of which video codecs can be decoded / encoded by the GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 in hardware in order to minimize the processor load.
- h264
- Decode / Encode
- h265 / HEVC
- Decode / Encode
- VP8
- Decode
- VP9
- Decode
- AV1
- No
The dimensions of the GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 are 295 mm in length, 143 mm in height and 52 mm in width. Thus 3 PCIe-Slots are needed in a case.
- Length
- 295 mm
- Height
- 143 mm
- Width
- 52 mm
- Width (Slots)
- 3 PCIe-Slots
- SFF-Ready
- No
The GALAX GeForce RTX 2060 SUPER EX (1-Click OC) V2 is manufactured in a structure width of 12 nm and has a PCIe 3.0 x 16 lanes interface. The graphics card was released in Q3/2019.
- GPU Interface
- PCIe 3.0 x 16
- Release date
- Q3/2019
- Launch Price
- 399 $ (Reference)
- Structure size
- 12 nm
- Part-no
- 26ISL6MPX2SE
