GPUThe GIGABYTE Radeon RX 7900 XTX ELITE 24G has 96 execution units with 6144 shaders. This gives the graphics card a theoretical FP32 computing power of 65.86 TFLOPS. |
|
Based on: | AMD Radeon RX 7900 XTX |
GPU Chip: | Navi 31 (RDNA 3) |
Streaming Multiprocessors: | 96 |
Shader: | 6144 |
Render Output Units: | 192 |
Texture Units: | 384 |
Raytracing Cores: | 96 |
MemoryThe GIGABYTE Radeon RX 7900 XTX ELITE 24G is equipped with 24 GB graphics memory of the type GDDR6. The memory clock of the graphics card is 2.500 GHz and the speed is 20 Gbps. |
|
Memory Size: | 24 GB |
Memory Type: | GDDR6 |
Memory Clock: | 2.500 GHz |
Memory Speed: | 20.0 Gbps |
Memory bandwidth: | 960 GB/s |
Memory Interface: | 384 bit |
Clock SpeedsThe base frequency of this graphics card is 1.900 GHz and the manufacturer specifies the maximum turbo clock as 2.680 GHz. If supported (see below), the performance can be further increased by overclocking. |
|
Base Clock: | 1.900 GHz |
Boost Clock: | 2.680 GHz+ 7 % |
Avg (Game) Clock: | 2.510 GHz+ 9 % |
Overclocking: | Yes |
Thermal DesignThe GIGABYTE Radeon RX 7900 XTX ELITE 24G is powered by 3 x 8-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 355 W. |
|
TDP: | 355 W |
TDP (up): | -- |
Tjunction max: | 97 °C |
PCIe-Power: | 3 x 8-Pin |
Cooler & FansGraphics processor and graphics memory of the GIGABYTE Radeon RX 7900 XTX ELITE 24G are cooled by a Air cooling. |
|
Fan-Type: | Axial |
Fan 1: | 3 x 100 mm |
Fan 2: | -- |
Cooler-Type: | Air cooling |
Noise (Idle): | 0 dB / Silent |
Noise (Load): | -- |
ConnectivityUp to 4 monitors can be operated with the GIGABYTE Radeon RX 7900 XTX ELITE 24G. |
|
Max. Displays: | 4 |
HDCP-Version: | 2.3 |
HDMI Ports: | 2x HDMI v2.1 |
DP Ports: | 2x DP v2.1 |
DVI Ports: | -- |
VGA Ports: | -- |
USB-C Ports: | -- |
FeaturesetWith the GIGABYTE Radeon RX 7900 XTX ELITE 24G it is possible to operate a screen with a resolution of up to 7680x4320 pixels. Furthermore, the DirectX standard version 12_2 (Ultimate) is supported. |
|
Max. resolution: | 7680x4320 |
DirectX: | 12_2 (Ultimate) |
Raytracing: | Yes |
DLSS / FSR: | Yes |
LED: | GIGABYTE RGB Fusion |
Supported Video CodecsThis area lists the video codecs that the GIGABYTE Radeon RX 7900 XTX ELITE 24G can decode or encode in hardware in order to minimize the processor load, which leads to lower power consumption. |
|
h264: | Decode / Encode |
h265 / HEVC: | Decode / Encode |
VP8: | Decode / Encode |
VP9: | Decode / Encode |
AV1: | Decode / Encode |
DimensionsThe GIGABYTE Radeon RX 7900 XTX ELITE 24G needs the space of 4 PCIe-Slots in a case. It is 335 mm long, 137 mm high and 69 mm wide. |
|
Length: | 335 mm |
Height: | 137 mm |
Width: | 69 mm |
Width (Slots): | 4 PCIe-Slots |
Weight: | -- |
Additional dataThe GIGABYTE Radeon RX 7900 XTX ELITE 24G was released in Q4/2022 at a price of 999 $ (Reference). The graphics card manufactured in 5 nm is connected to the system via PCIe 4 x 16 lanes. |
|
GPU Interface: | PCIe 4 x 16 |
Release date: | Q4/2022 |
Launch Price: | 999 $ (Reference) |
Structure size: | 5 nm |
Part-no: | GV-R79XTXAORUS E-24GD |
Documents: | data sheet |
