INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
Benchmark and Specs
Last updated:
Benchmark and Specs
Here we show you benchmarks and technical data for the INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB. The graphics card is based on the NVIDIA GeForce GTX 1060 6GB (Pascal) and has 6 GB GDDR5 graphics memory with a memory bandwidth of 192 GB/s. The INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB has 10 execution units with 1280 shaders.
GPUThe INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB has 1280 shaders and 10 execution units. The graphics card thus achieves a theoretical FP32 computing power of 4.54 TFLOPS. |
|
| Based on: | NVIDIA GeForce GTX 1060 6GB |
| GPU Chip: | GP106-400-A1 (Pascal) |
| Streaming Multiprocessors: | 10 |
| Shader: | 1280 |
| Render Output Units: | 48 |
| Texture Units: | 80 |
| Raytracing Cores: | 0 |
MemoryThe INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB can use 6 GB graphics memory of the type GDDR5. The graphics card thus achieves a memory bandwidth of 192 GB/s on a 192 bit wide memory interface. |
|
| Memory Size: | 6 GB |
| Memory Type: | GDDR5 |
| Memory Clock: | 2.002 GHz |
| Memory Speed: | 8.0 Gbps |
| Memory bandwidth: | 192 GB/s |
| Memory Interface: | 192 bit |
Clock SpeedsThe base clock frequency of the INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB is 1.556 GHz. A high clock frequency (even in turbo mode) can greatly increase the speed of a graphics card. |
|
| Base Clock: | 1.556 GHz + 3 % |
| Boost Clock: | 1.771 GHz+ 4 % |
| Avg (Game) Clock: | |
| Overclocking: | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB is 150 W. The graphics card is supplied with energy via the 1 x 8-Pin connector. |
|
| TDP: | 150 W+ 25 % |
| TDP (up): | -- |
| Tjunction max: | 94 °C |
| PCIe-Power: | 1 x 8-Pin |
Cooler & FansThe INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB has a total of 3 Axial fans to cool the graphics processor and graphics memory. |
|
| Fan-Type: | Axial |
| Fan 1: | 3 x 90 mm |
| Fan 2: | -- |
| Cooler-Type: | Air cooling |
| Noise (Idle): | -- |
| Noise (Load): | -- |
ConnectivityUp to 4 screens can be connected to the INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB. |
|
| Max. Displays: | 4 |
| HDCP-Version: | 2.2 |
| HDMI Ports: | 1x HDMI v2.0b |
| DP Ports: | 1x DP v1.4 |
| DVI Ports: | 2 |
| VGA Ports: | -- |
| USB-C Ports: | -- |
FeaturesetThe INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB has a maximum resolution of 7680x4320 pixels. The graphics card supports the DirectX 12_1 standard. |
|
| Max. resolution: | 7680x4320 |
| DirectX: | 12_1 |
| Raytracing: | No |
| DLSS / FSR: | Yes |
| LED: | ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light |
Supported Video CodecsThe video codecs accelerated in hardware by the INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB reduce the processor load and ensure lower energy consumption. |
|
| h264: | Decode / Encode |
| h265 / HEVC: | Decode / Encode |
| VP8: | No |
| VP9: | Decode |
| AV1: | No |
DimensionsThe INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB is 302 mm long and 115 mm high. With a width of --, the graphics card requires 3 PCIe-Slots in the case. |
|
| Length: | 302 mm |
| Height: | 115 mm |
| Width: | -- |
| Width (Slots): | 3 PCIe-Slots |
| Weight: | -- |
Additional dataThe INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB made in 16 nm was published in Q4/2018 for 249 $ (Reference). |
|
| GPU Interface: | PCIe 3.0 x 16 |
| Release date: | Q4/2018 |
| Launch Price: | 249 $ (Reference) |
| Structure size: | 16 nm |
| Part-no: | C1060-9SDN-N5GSX |
| Documents: | -- |
1.556 GHz, 6 GB (150 W TDP)
Buy this graphic card at amazon!
Rate this graphics card
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
6 GB GDDR5 |
||
|
NVIDIA GeForce GTX 1060 6GB
Average of gpu group |
||
Port Royal (Raytracing)
|
|
INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
6 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB
Average of gpu group |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
3840x2160 (2160p)
|
|
INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
6 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB
Average of gpu group |
||
2560x1440 (1440p)
|
|
INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
6 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB
Average of gpu group |
||
1920x1080 (1080p)
|
|
INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
6 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB
Average of gpu group |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
6 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB
Average of gpu group |
||
Geekbench 6 - Vulkan
|
|
INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
6 GB GDDR5 |
||
|
|
NVIDIA GeForce GTX 1060 6GB
Average of gpu group |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
INNO3D GeForce GTX 1060 iCHILL X3 V3 6GB
6 GB GDDR5 |
||
