The INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4 has 38 execution units with 4864 shaders. This gives the graphics card a theoretical FP32 computing power of 16.49 TFLOPS.
- GPU Chip
- GA104-202-A1 (Ampere)
- Streaming Multiprocessors
- 38
- Shader
- 4864
- Render Output Units
- 80
- Texture Units
- 152
- Raytracing Cores
- 38
The INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4 is equipped with 8 GB graphics memory of the type GDDR6X. The memory clock of the graphics card is 1.188 GHz and the speed is 19 Gbps.
- Memory Size
- 8 GB
- Memory Type
- GDDR6X
- Memory Clock
- 1.188 GHz
- Memory Speed
- 19.0 Gbps
- Memory bandwidth
- 608 GB/s
- Memory Interface
- 256 bit
The base frequency of this graphics card is 1.410 GHz and the manufacturer specifies the maximum turbo clock as 1.695 GHz. If supported (see below), the performance can be further increased by overclocking.
- Base Clock
- 1.410 GHz
- Boost Clock
- 1.695 GHz+2 %
- Overclocking
- Yes
The INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4 is powered by 1 x 8-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 225 W.
- TDP
- 225 W
- Tjunction max
- 93 °C
- PCIe-Power
- 1 x 8-Pin
Graphics processor and graphics memory of the INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4 are cooled by a Air cooling.
- Fan-Type
- Axial
- Fan 1
- 3 x 90 mm
- Fan 2
- 1 x 45 mm
- Cooler-Type
- Air cooling
- Noise (Idle)
- 0 dB / Silent
Up to 4 monitors can be operated with the INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4.
- Max. Displays
- 4
- HDCP
- 2.3
- HDMI
- 1x HDMI 2.1
- DisplayPort
- 3x DP 1.4a
With the INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4 it is possible to operate a screen with a resolution of up to 7680x4320 pixels. Furthermore, the DirectX standard version 12_2 (Ultimate) is supported.
- Max. resolution
- 7680x4320
- DirectX
- 12_2 (Ultimate)
- Raytracing
- Yes
- DLSS / FSR
- Yes
- LED
- Addressable LED
This area lists the video codecs that the INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4 can decode or encode in hardware in order to minimize the processor load, which leads to lower power consumption.
- h264
- Decode / Encode
- h265 / HEVC
- Decode / Encode
- VP8
- Decode
- VP9
- Decode
- AV1
- Decode
The INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4 needs the space of 3 PCIe-Slots in a case. It is 300 mm long, 135 mm high and -- wide.
- Length
- 300 mm
- Height
- 135 mm
- Width (Slots)
- 3 PCIe-Slots
- SFF-Ready
- No
The INNO3D GeForce RTX 3060 Ti GDDR6X iCHILL X4 was released in Q4/2022 at a price of 399 $. The graphics card manufactured in 8 nm is connected to the system via PCIe 4.0 x 16 lanes.
- GPU Interface
- PCIe 4.0 x 16
- Release date
- Q4/2022
- Launch Price
- 399 $ (Reference)
- Structure size
- 8 nm
- Part-no
- C306T4-086XX-1820VA35R
