GPUThe INNO3D GeForce RTX 3080 Twin X2 OC LHR is equipped with 68 execution and 8704 shader units. With single precision, a theoretical FP32 computing power of 30.03 TFLOPS is achieved. |
|
Based on: | NVIDIA GeForce RTX 3080 LHR |
GPU Chip: | GA102-202-K1-A1 (Ampere) |
Streaming Multiprocessors: | 68 |
Shader: | 8704 |
Render Output Units: | 96 |
Texture Units: | 272 |
Raytracing Cores: | 68 |
MemoryThe INNO3D GeForce RTX 3080 Twin X2 OC LHR has a 320 bit wide memory interface, with which a memory bandwidth of 760 GB/s is achieved. In total, 10 GB GDDR6X graphics memory is available for the graphics card. |
|
Memory Size: | 10 GB |
Memory Type: | GDDR6X |
Memory Clock: | 1.188 GHz |
Memory Speed: | 19.0 Gbps |
Memory bandwidth: | 760 GB/s |
Memory Interface: | 320 bit |
Clock SpeedsThe manufacturer specifies the memory clock of the INNO3D GeForce RTX 3080 Twin X2 OC LHR with 1.440 GHz (base clock) or with 1.725 GHz (turbo clock). If overclocking is supported (see below), the clock rate can be increased even further. |
|
Base Clock: | 1.440 GHz |
Boost Clock: | 1.725 GHz+ 1 % |
Avg (Game) Clock: | |
Overclocking: | Yes |
Thermal DesignThe INNO3D GeForce RTX 3080 Twin X2 OC LHR has 2 x 8-Pin plugs, which supply the graphics card with energy. The maximum operating temperature of the card is 93 °C. |
|
TDP: | 320 W |
TDP (up): | 370 W |
Tjunction max: | 93 °C |
PCIe-Power: | 2 x 8-Pin |
Cooler & FansThe INNO3D GeForce RTX 3080 Twin X2 OC LHR is equipped with 2 Axial main fans, which are used to cool the graphics processor and graphics memory. |
|
Fan-Type: | Axial |
Fan 1: | 2 x 90 mm |
Fan 2: | -- |
Cooler-Type: | Air cooling |
Noise (Idle): | 0 dB / Silent |
Noise (Load): | 42-44 dB |
ConnectivityUp to 4 screens can be connected to the INNO3D GeForce RTX 3080 Twin X2 OC LHR, whereby the backward-compatible HDCP copy protection is supported in the 2.3 version. |
|
Max. Displays: | 4 |
HDCP-Version: | 2.3 |
HDMI Ports: | 1x HDMI v2.1 |
DP Ports: | 3x DP v1.4a |
DVI Ports: | -- |
VGA Ports: | -- |
USB-C Ports: | -- |
FeaturesetThe INNO3D GeForce RTX 3080 Twin X2 OC LHR supports a maximum resolution of 7680x4320 pixels and the DirectX standard version 12_2 (Ultimate). |
|
Max. resolution: | 7680x4320 |
DirectX: | 12_2 (Ultimate) |
Raytracing: | Yes |
DLSS / FSR: | Yes |
LED: | No LED lighting |
Supported Video CodecsHere is a list of which video codecs can be decoded / encoded by the INNO3D GeForce RTX 3080 Twin X2 OC LHR in hardware in order to minimize the processor load. |
|
h264: | Decode / Encode |
h265 / HEVC: | Decode / Encode |
VP8: | Decode |
VP9: | Decode |
AV1: | Decode |
DimensionsThe dimensions of the INNO3D GeForce RTX 3080 Twin X2 OC LHR are 274 mm in length, 120 mm in height and -- in width. Thus 3 PCIe-Slots are needed in a case. |
|
Length: | 274 mm |
Height: | 120 mm |
Width: | -- |
Width (Slots): | 3 PCIe-Slots |
Weight: | -- |
Additional dataThe INNO3D GeForce RTX 3080 Twin X2 OC LHR is manufactured in a structure width of 8 nm and has a PCIe 4.0 x 16 lanes interface. The graphics card was released in Q2/2021. |
|
GPU Interface: | PCIe 4.0 x 16 |
Release date: | Q2/2021 |
Launch Price: | 829 $ |
Structure size: | 8 nm |
Part-no: | N30802-106XX-1810VA34H |
Documents: | data sheet |
