The KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR has 38 execution units with 4864 shaders. This gives the graphics card a theoretical FP32 computing power of 16.35 TFLOPS.
- GPU Chip
- GA104-202-A1 (Ampere)
- Streaming Multiprocessors
- 38
- Shader
- 4864
- Render Output Units
- 80
- Texture Units
- 152
- Raytracing Cores
- 38
The KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR is equipped with 8 GB graphics memory of the type GDDR6. The memory clock of the graphics card is 1.750 GHz and the speed is 14 Gbps.
- Memory Size
- 8 GB
- Memory Type
- GDDR6
- Memory Clock
- 1.750 GHz
- Memory Speed
- 14.0 Gbps
- Memory bandwidth
- 448 GB/s
- Memory Interface
- 256 bit
The base frequency of this graphics card is 1.410 GHz and the manufacturer specifies the maximum turbo clock as 1.680 GHz. If supported (see below), the performance can be further increased by overclocking.
- Base Clock
- 1.410 GHz
- Boost Clock
- 1.680 GHz+1 %
- Avg (Game) Clock
- 1.665 GHz
- Overclocking
- Yes
The KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR is powered by 1 x 8-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 200 W.
- TDP
- 200 W
- TDP (up)
- 220 W
- Tjunction max
- 93 °C
- PCIe-Power
- 1 x 8-Pin
Graphics processor and graphics memory of the KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR are cooled by a Air cooling.
- Fan-Type
- Axial
- Fan 1
- 2 x 90 mm
- Cooler-Type
- Air cooling
- Noise (Idle)
- 0 dB / Silent
Up to 4 monitors can be operated with the KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR.
- Max. Displays
- 4
- HDCP
- 2.3
- HDMI
- 1x HDMI 2.1
- DisplayPort
- 3x DP 1.4a
With the KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR it is possible to operate a screen with a resolution of up to 7680x4320 pixels. Furthermore, the DirectX standard version 12_2 (Ultimate) is supported.
- Max. resolution
- 7680x4320
- DirectX
- 12_2 (Ultimate)
- Raytracing
- Yes
- DLSS / FSR
- Yes
- LED
- Addressable LED
This area lists the video codecs that the KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR can decode or encode in hardware in order to minimize the processor load, which leads to lower power consumption.
- h264
- Decode / Encode
- h265 / HEVC
- Decode / Encode
- VP8
- Decode
- VP9
- Decode
- AV1
- Decode
The KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR needs the space of 2 PCIe-Slots in a case. It is 257 mm long, 132 mm high and 42 mm wide.
- Length
- 257 mm
- Height
- 132 mm
- Width
- 42 mm
- Width (Slots)
- 2 PCIe-Slots
- SFF-Ready
- No
The KFA2 GeForce RTX 3060 Ti (1-Click OC) LHR was released in Q2/2021 at a price of 459 $. The graphics card manufactured in 8 nm is connected to the system via PCIe 4.0 x 16 lanes.
- GPU Interface
- PCIe 4.0 x 16
- Release date
- Q2/2021
- Launch Price
- 459 $
- Structure size
- 8 nm
- Part-no
- 36ISL6MD1VQK
