GPUThe MANLI GeForce RTX 3060 Ti (M2480 + N630) is equipped with 38 execution and 4864 shader units. With single precision, a theoretical FP32 computing power of 16.20 TFLOPS is achieved. |
|
Based on: | NVIDIA GeForce RTX 3060 Ti |
GPU Chip: | GA104-200-A1 (Ampere) |
Streaming Multiprocessors: | 38 |
Shader: | 4864 |
Render Output Units: | 80 |
Texture Units: | 152 |
Raytracing Cores: | 38 |
MemoryThe MANLI GeForce RTX 3060 Ti (M2480 + N630) has a 256 bit wide memory interface, with which a memory bandwidth of 448 GB/s is achieved. In total, 8 GB GDDR6 graphics memory is available for the graphics card. |
|
Memory Size: | 8 GB |
Memory Type: | GDDR6 |
Memory Clock: | 1.750 GHz |
Memory Speed: | 14.0 Gbps |
Memory bandwidth: | 448 GB/s |
Memory Interface: | 256 bit |
Clock SpeedsThe manufacturer specifies the memory clock of the MANLI GeForce RTX 3060 Ti (M2480 + N630) with 1.410 GHz (base clock) or with 1.665 GHz (turbo clock). If overclocking is supported (see below), the clock rate can be increased even further. |
|
Base Clock: | 1.410 GHz |
Boost Clock: | 1.665 GHz |
Avg (Game) Clock: | |
Overclocking: | Yes |
Thermal DesignThe MANLI GeForce RTX 3060 Ti (M2480 + N630) has 1 x 8-Pin plugs, which supply the graphics card with energy. The maximum operating temperature of the card is 93 °C. |
|
TDP: | 200 W |
TDP (up): | 220 W |
Tjunction max: | 93 °C |
PCIe-Power: | 1 x 8-Pin |
Cooler & FansThe MANLI GeForce RTX 3060 Ti (M2480 + N630) is equipped with 2 Axial main fans, which are used to cool the graphics processor and graphics memory. |
|
Fan-Type: | Axial |
Fan 1: | 2 x 90 mm |
Fan 2: | -- |
Cooler-Type: | Air cooling |
Noise (Idle): | 0 dB / Silent |
Noise (Load): | -- |
ConnectivityUp to 4 screens can be connected to the MANLI GeForce RTX 3060 Ti (M2480 + N630), whereby the backward-compatible HDCP copy protection is supported in the 2.3 version. |
|
Max. Displays: | 4 |
HDCP-Version: | 2.3 |
HDMI Ports: | 1x HDMI v2.1 |
DP Ports: | 3x DP v1.4a |
DVI Ports: | -- |
VGA Ports: | -- |
USB-C Ports: | -- |
FeaturesetThe MANLI GeForce RTX 3060 Ti (M2480 + N630) supports a maximum resolution of 7680x4320 pixels and the DirectX standard version 12_2 (Ultimate). |
|
Max. resolution: | 7680x4320 |
DirectX: | 12_2 (Ultimate) |
Raytracing: | Yes |
DLSS / FSR: | Yes |
LED: | No LED lighting |
Supported Video CodecsHere is a list of which video codecs can be decoded / encoded by the MANLI GeForce RTX 3060 Ti (M2480 + N630) in hardware in order to minimize the processor load. |
|
h264: | Decode / Encode |
h265 / HEVC: | Decode / Encode |
VP8: | Decode |
VP9: | Decode |
AV1: | Decode |
DimensionsThe dimensions of the MANLI GeForce RTX 3060 Ti (M2480 + N630) are 251 mm in length, 112 mm in height and 42 mm in width. Thus 2 PCIe-Slots are needed in a case. |
|
Length: | 251 mm |
Height: | 112 mm |
Width: | 42 mm |
Width (Slots): | 2 PCIe-Slots |
Weight: | -- |
Additional dataThe MANLI GeForce RTX 3060 Ti (M2480 + N630) is manufactured in a structure width of 8 nm and has a PCIe 4.0 x 16 lanes interface. The graphics card was released in Q4/2020. |
|
GPU Interface: | PCIe 4.0 x 16 |
Release date: | Q4/2020 |
Launch Price: | 399 $ (Reference) |
Structure size: | 8 nm |
Part-no: | M-NRTX3060TI/6RGHPPP-M2480 |
Documents: | data sheet |
