Manli Polar Fox GeForce RTX 5060 OC Benchmark and Specs

The Manli Polar Fox GeForce RTX 5060 OC is equipped with 30 execution and 3840 shader units. With single precision, a theoretical FP32 computing power of 19.59 TFLOPS is achieved.

Based on

NVIDIA GeForce RTX 5060

GPU Chip

GB206-250-A1 (Blackwell 2.0)

Streaming Multiprocessors

30

Shader

3840

Render Output Units

48

Texture Units

120

Raytracing Cores

30

The Manli Polar Fox GeForce RTX 5060 OC has a 128 bit wide memory interface, with which a memory bandwidth of 448 GB/s is achieved. In total, 8 GB GDDR7 graphics memory is available for the graphics card.

Memory Size

8 GB

Memory Type

GDDR7

Memory Clock

1.750 GHz

Memory Speed

28.0 Gbps

Memory bandwidth

448 GB/s

Memory Interface

128 bit

The manufacturer specifies the memory clock of the Manli Polar Fox GeForce RTX 5060 OC with 2.280 GHz (base clock) or with 2.550 GHz (turbo clock). If overclocking is supported (see below), the clock rate can be increased even further.

Base Clock

2.280 GHz

Boost Clock

2.550 GHz+2 %

Overclocking

Yes

The Manli Polar Fox GeForce RTX 5060 OC has 1 x 8-Pin plugs, which supply the graphics card with energy. The maximum operating temperature of the card is 89 °C.

TDP

145 W

Tjunction max

89 °C

PCIe-Power

1 x 8-Pin

The Manli Polar Fox GeForce RTX 5060 OC is equipped with 2 Axial main fans, which are used to cool the graphics processor and graphics memory.

Fan-Type

Axial

Fan 1

2 x 90 mm

Cooler-Type

Air cooling

Noise (Idle)

0 dB / Silent

Up to 4 screens can be connected to the Manli Polar Fox GeForce RTX 5060 OC, whereby the backward-compatible HDCP copy protection is supported in the 2.3 version.

Max. Displays

4

HDCP

2.3

HDMI

1x HDMI 2.1b

DisplayPort

3x DP 2.1b

The Manli Polar Fox GeForce RTX 5060 OC supports a maximum resolution of 7680x4320 pixels and the DirectX standard version 12_2 (Ultimate).

Max. resolution

7680x4320

DirectX

12_2 (Ultimate)

Raytracing

Yes

DLSS / FSR

Yes

LED

Addressable LED

Here is a list of which video codecs can be decoded / encoded by the Manli Polar Fox GeForce RTX 5060 OC in hardware in order to minimize the processor load.

h264

Decode / Encode

h265 / HEVC

Decode / Encode

VP8

Decode / Encode

VP9

Decode / Encode

AV1

Decode / Encode

The dimensions of the Manli Polar Fox GeForce RTX 5060 OC are 240 mm in length, 126 mm in height and 50 mm in width. Thus 3 PCIe-Slots are needed in a case.

Length

240 mm

Height

126 mm

Width

50 mm

Width (Slots)

3 PCIe-Slots

SFF-Ready

No

The Manli Polar Fox GeForce RTX 5060 OC is manufactured in a structure width of 5 nm and has a PCIe 5 x 8 lanes interface. The graphics card was released in Q4/2025.

GPU Interface

PCIe 5 x 8

Release date

Q4/2025

Launch Price

299 $ (Reference)

Structure size

5 nm

Part-no

M-N506PO/D78G-M2660

Documents

data sheet
