The MSI GeForce RTX 2070 SUPER VENTUS GP has 2560 shaders and 40 execution units. The graphics card thus achieves a theoretical FP32 computing power of 9.06 TFLOPS.
- GPU Chip
- TU104 (Turing)
- Streaming Multiprocessors
- 40
- Shader
- 2560
- Render Output Units
- 64
- Texture Units
- 160
- Raytracing Cores
- 40
The MSI GeForce RTX 2070 SUPER VENTUS GP can use 8 GB graphics memory of the type GDDR6. The graphics card thus achieves a memory bandwidth of 448 GB/s on a 256 bit wide memory interface.
- Memory Size
- 8 GB
- Memory Type
- GDDR6
- Memory Clock
- 1.750 GHz
- Memory Speed
- 14.0 Gbps
- Memory bandwidth
- 448 GB/s
- Memory Interface
- 256 bit
The base clock frequency of the MSI GeForce RTX 2070 SUPER VENTUS GP is 1.605 GHz. A high clock frequency (even in turbo mode) can greatly increase the speed of a graphics card.
- Base Clock
- 1.605 GHz
- Boost Clock
- 1.770 GHz
- Overclocking
- Yes
The TDP (Thermal Design Power) of the MSI GeForce RTX 2070 SUPER VENTUS GP is 235 W. The graphics card is supplied with energy via the 1 x 6-Pin, 1 x 8-Pin connector.
- TDP
- 235 W+9 %
- Tjunction max
- 88 °C
- PCIe-Power
- 1 x 6-Pin, 1 x 8-Pin
The MSI GeForce RTX 2070 SUPER VENTUS GP has a total of 2 Axial fans to cool the graphics processor and graphics memory.
- Fan-Type
- Axial
- Fan 1
- 2 x 90 mm
- Cooler-Type
- Air cooling
- Noise (Idle)
- 0 dB / Silent
Up to 4 screens can be connected to the MSI GeForce RTX 2070 SUPER VENTUS GP.
- Max. Displays
- 4
- HDCP
- 2.2
- HDMI
- 1x HDMI 2.0b
- DisplayPort
- 3x DP 1.4a
The MSI GeForce RTX 2070 SUPER VENTUS GP has a maximum resolution of 7680x4320 pixels. The graphics card supports the DirectX 12_2 (Ultimate) standard.
- Max. resolution
- 7680x4320
- DirectX
- 12_2 (Ultimate)
- Raytracing
- Yes
- DLSS / FSR
- Yes
- LED
- No LED lighting
The video codecs accelerated in hardware by the MSI GeForce RTX 2070 SUPER VENTUS GP reduce the processor load and ensure lower energy consumption.
- h264
- Decode / Encode
- h265 / HEVC
- Decode / Encode
- VP8
- Decode
- VP9
- Decode
- AV1
- No
The MSI GeForce RTX 2070 SUPER VENTUS GP is 258 mm long and 127 mm high. With a width of 43 mm, the graphics card requires 2 PCIe-Slots in the case.
- Length
- 258 mm
- Height
- 127 mm
- Width
- 43 mm
- Width (Slots)
- 2 PCIe-Slots
- Weight
- 829 g
- SFF-Ready
- No
The MSI GeForce RTX 2070 SUPER VENTUS GP made in 12 nm was published in Q1/2020 for 499 $.
- GPU Interface
- PCIe 3.0 x 16
- Release date
- Q1/2020
- Launch Price
- 499 $ (Reference)
- Structure size
- 12 nm
