GPUThe MSI GeForce RTX 3080 SUPRIM SE 12G LHR has 70 execution units with 8960 shaders. This gives the graphics card a theoretical FP32 computing power of 31.72 TFLOPS. |
|
Based on: | NVIDIA GeForce RTX 3080 12GB |
GPU Chip: | GA102 (Ampere) |
Streaming Multiprocessors: | 70 |
Shader: | 8960 |
Render Output Units: | 112 |
Texture Units: | 280 |
Raytracing Cores: | 70 |
MemoryThe MSI GeForce RTX 3080 SUPRIM SE 12G LHR is equipped with 12 GB graphics memory of the type GDDR6X. The memory clock of the graphics card is 1.188 GHz and the speed is 19 Gbps. |
|
Memory Size: | 12 GB |
Memory Type: | GDDR6X |
Memory Clock: | 1.188 GHz |
Memory Speed: | 19.0 Gbps |
Memory bandwidth: | 912 GB/s |
Memory Interface: | 384 bit |
Clock SpeedsThe base frequency of this graphics card is 1.260 GHz and the manufacturer specifies the maximum turbo clock as 1.770 GHz. If supported (see below), the performance can be further increased by overclocking. |
|
Base Clock: | 1.260 GHz |
Boost Clock: | 1.770 GHz+ 4 % |
Avg (Game) Clock: | 1.755 GHz |
Overclocking: | Yes |
Thermal DesignThe MSI GeForce RTX 3080 SUPRIM SE 12G LHR is powered by 3 x 8-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 350 W. |
|
TDP: | 350 W |
TDP (up): | -- |
Tjunction max: | 93 °C |
PCIe-Power: | 3 x 8-Pin |
Cooler & FansGraphics processor and graphics memory of the MSI GeForce RTX 3080 SUPRIM SE 12G LHR are cooled by a Air cooling. |
|
Fan-Type: | Axial |
Fan 1: | 3 x 100 mm |
Fan 2: | -- |
Cooler-Type: | Air cooling |
Noise (Idle): | 0 dB / Silent |
Noise (Load): | -- |
ConnectivityUp to 4 monitors can be operated with the MSI GeForce RTX 3080 SUPRIM SE 12G LHR. |
|
Max. Displays: | 4 |
HDCP-Version: | 2.3 |
HDMI Ports: | 1x HDMI v2.1 |
DP Ports: | 3x DP v1.4a |
DVI Ports: | -- |
VGA Ports: | -- |
USB-C Ports: | -- |
FeaturesetWith the MSI GeForce RTX 3080 SUPRIM SE 12G LHR it is possible to operate a screen with a resolution of up to 7680x4320 pixels. Furthermore, the DirectX standard version 12_2 (Ultimate) is supported. |
|
Max. resolution: | 7680x4320 |
DirectX: | 12_2 (Ultimate) |
Raytracing: | Yes |
DLSS / FSR: | Yes |
LED: | MSI Mystic Light |
Supported Video CodecsThis area lists the video codecs that the MSI GeForce RTX 3080 SUPRIM SE 12G LHR can decode or encode in hardware in order to minimize the processor load, which leads to lower power consumption. |
|
h264: | Decode / Encode |
h265 / HEVC: | Decode / Encode |
VP8: | Decode |
VP9: | Decode |
AV1: | Decode |
DimensionsThe MSI GeForce RTX 3080 SUPRIM SE 12G LHR needs the space of 3 PCIe-Slots in a case. It is 336 mm long, 140 mm high and 61 mm wide. |
|
Length: | 336 mm |
Height: | 140 mm |
Width: | 61 mm |
Width (Slots): | 3 PCIe-Slots |
Weight: | 1903 g |
Additional dataThe MSI GeForce RTX 3080 SUPRIM SE 12G LHR was released in Q2/2022 at a price of 699 $ (Reference). The graphics card manufactured in 8 nm is connected to the system via PCIe 4.0 x 16 lanes. |
|
GPU Interface: | PCIe 4.0 x 16 |
Release date: | Q2/2022 |
Launch Price: | 699 $ (Reference) |
Structure size: | 8 nm |
Part-no: | -- |
Documents: | data sheet |
