GPUThe PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan is equipped with 48 execution and 3072 shader units. With single precision, a theoretical FP32 computing power of 11.43 TFLOPS is achieved. |
|
Based on: | NVIDIA GeForce RTX 2080 SUPER |
GPU Chip: | TU104 (Turing) |
Streaming Multiprocessors: | 48 |
Shader: | 3072 |
Render Output Units: | 64 |
Texture Units: | 192 |
Raytracing Cores: | 48 |
MemoryThe PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan has a 256 bit wide memory interface, with which a memory bandwidth of 496 GB/s is achieved. In total, 8 GB GDDR6 graphics memory is available for the graphics card. |
|
Memory Size: | 8 GB |
Memory Type: | GDDR6 |
Memory Clock: | 1.938 GHz |
Memory Speed: | 15.5 Gbps |
Memory bandwidth: | 496 GB/s |
Memory Interface: | 256 bit |
Clock SpeedsThe manufacturer specifies the memory clock of the PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan with 1.650 GHz (base clock) or with 1.860 GHz (turbo clock). If overclocking is supported (see below), the clock rate can be increased even further. |
|
Base Clock: | 1.650 GHz |
Boost Clock: | 1.860 GHz+ 2 % |
Avg (Game) Clock: | 1.815 GHz |
Overclocking: | Yes |
Thermal DesignThe PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan has 1 x 6-Pin, 1 x 8-Pin plugs, which supply the graphics card with energy. The maximum operating temperature of the card is 89 °C. |
|
TDP: | 250 W |
TDP (up): | 280 W |
Tjunction max: | 89 °C |
PCIe-Power: | 1 x 6-Pin, 1 x 8-Pin |
Cooler & FansThe PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan is equipped with 3 Axial main fans, which are used to cool the graphics processor and graphics memory. |
|
Fan-Type: | Axial |
Fan 1: | 2 x 90 mm |
Fan 2: | 1 x 75 mm |
Cooler-Type: | Air cooling |
Noise (Idle): | 0 dB / Silent |
Noise (Load): | 44 dB |
ConnectivityUp to 4 screens can be connected to the PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan, whereby the backward-compatible HDCP copy protection is supported in the 2.2 version. |
|
Max. Displays: | 4 |
HDCP-Version: | 2.2 |
HDMI Ports: | 1x HDMI v2.0b |
DP Ports: | 3x DP v1.4a |
DVI Ports: | -- |
VGA Ports: | -- |
USB-C Ports: | -- |
FeaturesetThe PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan supports a maximum resolution of 7680x4320 pixels and the DirectX standard version 12_2 (Ultimate). |
|
Max. resolution: | 7680x4320 |
DirectX: | 12_2 (Ultimate) |
Raytracing: | Yes |
DLSS / FSR: | Yes |
LED: | No LED lighting |
Supported Video CodecsHere is a list of which video codecs can be decoded / encoded by the PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan in hardware in order to minimize the processor load. |
|
h264: | Decode / Encode |
h265 / HEVC: | Decode / Encode |
VP8: | Decode |
VP9: | Decode |
AV1: | No |
DimensionsThe dimensions of the PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan are 314 mm in length, 128 mm in height and 44 mm in width. Thus 2 PCIe-Slots are needed in a case. |
|
Length: | 314 mm |
Height: | 128 mm |
Width: | 44 mm |
Width (Slots): | 2 PCIe-Slots |
Weight: | -- |
Additional dataThe PNY GeForce RTX 2080 SUPER XLR8 Gaming OC Triple Fan is manufactured in a structure width of 12 nm and has a PCIe 3.0 x 16 lanes interface. The graphics card was released in Q3/2019. |
|
GPU Interface: | PCIe 3.0 x 16 |
Release date: | Q3/2019 |
Launch Price: | 829 $ |
Structure size: | 12 nm |
Part-no: | VCG20808STFMPB-O |
Documents: | data sheet |
