The PNY GeForce RTX 5070 Slim Dual Fan Overclocked has 6144 shaders and 48 execution units. The graphics card thus achieves a theoretical FP32 computing power of 31.79 TFLOPS.
- GPU Chip
- GB205-300-A1 (Blackwell)
- Streaming Multiprocessors
- 48
- Shader
- 6144
- Render Output Units
- 64
- Texture Units
- 192
- Raytracing Cores
- 48
The PNY GeForce RTX 5070 Slim Dual Fan Overclocked can use 12 GB graphics memory of the type GDDR7. The graphics card thus achieves a memory bandwidth of 672 GB/s on a 192 bit wide memory interface.
- Memory Size
- 12 GB
- Memory Type
- GDDR7
- Memory Clock
- 1.750 GHz
- Memory Speed
- 28.0 Gbps
- Memory bandwidth
- 672 GB/s
- Memory Interface
- 192 bit
The base clock frequency of the PNY GeForce RTX 5070 Slim Dual Fan Overclocked is 2.165 GHz. A high clock frequency (even in turbo mode) can greatly increase the speed of a graphics card.
- Base Clock
- 2.165 GHz
- Boost Clock
- 2.587 GHz+3 %
- Overclocking
- Yes
The TDP (Thermal Design Power) of the PNY GeForce RTX 5070 Slim Dual Fan Overclocked is 250 W. The graphics card is supplied with energy via the 1 x 16-Pin connector.
- TDP
- 250 W
- Tjunction max
- 85 °C
- PCIe-Power
- 1 x 16-Pin
The PNY GeForce RTX 5070 Slim Dual Fan Overclocked has a total of 2 Axial fans to cool the graphics processor and graphics memory.
- Fan-Type
- Axial
- Fan 1
- 2 x 100 mm
- Cooler-Type
- Air cooling
- Noise (Idle)
- 0 dB / Silent
Up to 4 screens can be connected to the PNY GeForce RTX 5070 Slim Dual Fan Overclocked.
- Max. Displays
- 4
- HDCP
- 2.3
- HDMI
- 1x HDMI 2.1b
- DisplayPort
- 3x DP 2.1b
The PNY GeForce RTX 5070 Slim Dual Fan Overclocked has a maximum resolution of 7680x4320 pixels. The graphics card supports the DirectX 12_2 (Ultimate) standard.
- Max. resolution
- 7680x4320
- DirectX
- 12_2 (Ultimate)
- Raytracing
- Yes
- DLSS / FSR
- Yes
- LED
- No LED lighting
The video codecs accelerated in hardware by the PNY GeForce RTX 5070 Slim Dual Fan Overclocked reduce the processor load and ensure lower energy consumption.
- h264
- Decode / Encode
- h265 / HEVC
- Decode / Encode
- VP8
- Decode / Encode
- VP9
- Decode / Encode
- AV1
- Decode / Encode
The PNY GeForce RTX 5070 Slim Dual Fan Overclocked is 290 mm long and 128 mm high. With a width of 40 mm, the graphics card requires 2 PCIe-Slots in the case.
- Length
- 290 mm
- Height
- 128 mm
- Width
- 40 mm
- Width (Slots)
- 2 PCIe-Slots
- SFF-Ready
- Yes
The PNY GeForce RTX 5070 Slim Dual Fan Overclocked made in 5 nm was published in Q4/2025 for 549 $.
- GPU Interface
- PCIe 5 x 16
- Release date
- Q4/2025
- Launch Price
- 549 $ (Reference)
- Structure size
- 5 nm
- Part-no
- VCG507012DFSXPB1-O
