GPUThe ZOTAC Gaming GeForce RTX 3080 Trinity has 68 execution units with 8704 shaders. This gives the graphics card a theoretical FP32 computing power of 29.77 TFLOPS. |
|
Based on: | NVIDIA GeForce RTX 3080 |
GPU Chip: | GA102-200-K1-A1 (Ampere) |
Streaming Multiprocessors: | 68 |
Shader: | 8704 |
Render Output Units: | 96 |
Texture Units: | 272 |
Raytracing Cores: | 68 |
MemoryThe ZOTAC Gaming GeForce RTX 3080 Trinity is equipped with 10 GB graphics memory of the type GDDR6X. The memory clock of the graphics card is 1.188 GHz and the speed is 19 Gbps. |
|
Memory Size: | 10 GB |
Memory Type: | GDDR6X |
Memory Clock: | 1.188 GHz |
Memory Speed: | 19.0 Gbps |
Memory bandwidth: | 760 GB/s |
Memory Interface: | 320 bit |
Clock SpeedsThe base frequency of this graphics card is 1.440 GHz and the manufacturer specifies the maximum turbo clock as 1.710 GHz. If supported (see below), the performance can be further increased by overclocking. |
|
Base Clock: | 1.440 GHz |
Boost Clock: | 1.710 GHz |
Avg (Game) Clock: | |
Overclocking: | Yes |
Thermal DesignThe ZOTAC Gaming GeForce RTX 3080 Trinity is powered by 2 x 8-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 320 W. |
|
TDP: | 320 W |
TDP (up): | 374 W+ 1 % |
Tjunction max: | 93 °C |
PCIe-Power: | 2 x 8-Pin |
Cooler & FansGraphics processor and graphics memory of the ZOTAC Gaming GeForce RTX 3080 Trinity are cooled by a Air cooling. |
|
Fan-Type: | Axial |
Fan 1: | 3 x 100 mm |
Fan 2: | -- |
Cooler-Type: | Air cooling |
Noise (Idle): | 0 dB / Silent |
Noise (Load): | 41 dB |
ConnectivityUp to 4 monitors can be operated with the ZOTAC Gaming GeForce RTX 3080 Trinity. |
|
Max. Displays: | 4 |
HDCP-Version: | 2.3 |
HDMI Ports: | 1x HDMI v2.1 |
DP Ports: | 3x DP v1.4a |
DVI Ports: | -- |
VGA Ports: | -- |
USB-C Ports: | -- |
FeaturesetWith the ZOTAC Gaming GeForce RTX 3080 Trinity it is possible to operate a screen with a resolution of up to 7680x4320 pixels. Furthermore, the DirectX standard version 12_2 (Ultimate) is supported. |
|
Max. resolution: | 7680x4320 |
DirectX: | 12_2 (Ultimate) |
Raytracing: | Yes |
DLSS / FSR: | Yes |
LED: | ZOTAC SPECTRA |
Supported Video CodecsThis area lists the video codecs that the ZOTAC Gaming GeForce RTX 3080 Trinity can decode or encode in hardware in order to minimize the processor load, which leads to lower power consumption. |
|
h264: | Decode / Encode |
h265 / HEVC: | Decode / Encode |
VP8: | Decode |
VP9: | Decode |
AV1: | Decode |
DimensionsThe ZOTAC Gaming GeForce RTX 3080 Trinity needs the space of 3 PCIe-Slots in a case. It is 318 mm long, 121 mm high and 58 mm wide. |
|
Length: | 318 mm |
Height: | 121 mm |
Width: | 58 mm |
Width (Slots): | 3 PCIe-Slots |
Weight: | -- |
Additional dataThe ZOTAC Gaming GeForce RTX 3080 Trinity was released in Q4/2020 at a price of 749 $. The graphics card manufactured in 8 nm is connected to the system via PCIe 4.0 x 16 lanes. |
|
GPU Interface: | PCIe 4.0 x 16 |
Release date: | Q4/2020 |
Launch Price: | 749 $ |
Structure size: | 8 nm |
Part-no: | ZT-A30800D-10P |
Documents: | data sheet |
