ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
Benchmark and Specs
Last updated:
Benchmark and Specs
Here we show you benchmarks and technical data for the ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo. The graphics card is based on the NVIDIA GeForce RTX 3090 Ti (Ampere) and has 24 GB GDDR6X graphics memory with a memory bandwidth of 1008 GB/s. The ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo has 84 execution units with 10752 shaders.
GPUThe ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo has 10752 shaders and 84 execution units. The graphics card thus achieves a theoretical FP32 computing power of 40.65 TFLOPS. |
|
| Based on: | NVIDIA GeForce RTX 3090 Ti |
| GPU Chip: | GA102-350-A1 (Ampere) |
| Streaming Multiprocessors: | 84 |
| Shader: | 10752 |
| Render Output Units: | 112 |
| Texture Units: | 336 |
| Raytracing Cores: | 84 |
MemoryThe ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo can use 24 GB graphics memory of the type GDDR6X. The graphics card thus achieves a memory bandwidth of 1008 GB/s on a 384 bit wide memory interface. |
|
| Memory Size: | 24 GB |
| Memory Type: | GDDR6X |
| Memory Clock: | 1.313 GHz |
| Memory Speed: | 21.0 Gbps |
| Memory bandwidth: | 1008 GB/s |
| Memory Interface: | 384 bit |
Clock SpeedsThe base clock frequency of the ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo is 1.560 GHz. A high clock frequency (even in turbo mode) can greatly increase the speed of a graphics card. |
|
| Base Clock: | 1.560 GHz -7 % |
| Boost Clock: | 1.890 GHz + 2 % |
| Avg (Game) Clock: | |
| Overclocking: | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo is 450 W. The graphics card is supplied with energy via the 1 x 16-Pin connector. |
|
| TDP: | 450 W |
| TDP (up): | -- |
| Tjunction max: | 92 °C |
| PCIe-Power: | 1 x 16-Pin |
Cooler & FansThe ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo has a total of 3 Axial fans to cool the graphics processor and graphics memory. |
|
| Fan-Type: | Axial |
| Fan 1: | 3 x 100 mm |
| Fan 2: | -- |
| Cooler-Type: | Air cooling |
| Noise (Idle): | 0 dB / Silent |
| Noise (Load): | -- |
ConnectivityUp to 4 screens can be connected to the ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo. |
|
| Max. Displays: | 4 |
| HDCP-Version: | 2.3 |
| HDMI Ports: | 1x HDMI v2.1 |
| DP Ports: | 3x DP v1.4a |
| DVI Ports: | -- |
| VGA Ports: | -- |
| USB-C Ports: | -- |
FeaturesetThe ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo has a maximum resolution of 7680x4320 pixels. The graphics card supports the DirectX 12_2 (Ultimate) standard. |
|
| Max. resolution: | 7680x4320 |
| DirectX: | 12_2 (Ultimate) |
| Raytracing: | Yes |
| DLSS / FSR: | Yes |
| LED: | ZOTAC SPECTRA |
Supported Video CodecsThe video codecs accelerated in hardware by the ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo reduce the processor load and ensure lower energy consumption. |
|
| h264: | Decode / Encode |
| h265 / HEVC: | Decode / Encode |
| VP8: | Decode |
| VP9: | Decode |
| AV1: | Decode |
DimensionsThe ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo is 356 mm long and 150 mm high. With a width of 64 mm, the graphics card requires 4 PCIe-Slots in the case. |
|
| Length: | 356 mm |
| Height: | 150 mm |
| Width: | 64 mm |
| Width (Slots): | 4 PCIe-Slots |
| Weight: | -- |
Additional dataThe ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo made in 8 nm was published in Q1/2022 for 1,999 $ (Reference). |
|
| GPU Interface: | PCIe 4.0 x 16 |
| Release date: | Q1/2022 |
| Launch Price: | 1,999 $ (Reference) |
| Structure size: | 8 nm |
| Part-no: | ZT-A30910B-10P |
| Documents: | data sheet |
1.560 GHz, 24 GB (450 W TDP)
Buy this graphic card at amazon!
Rate this graphics card
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
Port Royal (Raytracing)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
Speed Way Graphics Score (Raytracing)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
3840x2160 (2160p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
2560x1440 (1440p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
1920x1080 (1080p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
The Last of Us Part 1
The Last of Us Part One is a game released by Sony in June 2013 exclusively for the Playstation and released for the PC in early 2023. The benchmark values here were determined at high details.
3840x2160 (2160p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
2560x1440 (1440p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
1920x1080 (1080p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
3840x2160 (2160p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
2560x1440 (1440p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
1920x1080 (1080p)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
Geekbench 6 - Vulkan
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
|
|
NVIDIA GeForce RTX 3090 Ti
Average of gpu group |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
ZOTAC GAMING GeForce RTX 3090 Ti AMP Extreme Holo
24 GB GDDR6X |
||
