NVIDIA GeForce GTX 1650 GDDR6
vs
GALAX GeForce GT 1030 Black DDR4
GPU comparison with benchmarksThe NVIDIA GeForce GTX 1650 GDDR6 has 896 shader units and these clock a maximum of 1.59 GHz which results in an FP32 computing power of 2.85 TFLOPS.
The GALAX GeForce GT 1030 Black DDR4 has 384 shader units and these clock at a maximum of 1.38 GHz and achieve an FP32 computing power of 1.06 TFLOPS. |
||
GPUThe NVIDIA GeForce GTX 1650 GDDR6 is equipped with a graphics chip of the Turing architecture, which has 14 streaming multiprocessors. The graphics card GALAX GeForce GT 1030 Black DDR4 is based on the Pascal architecture and is equipped with 3 execution units. |
||
| NVIDIA GeForce GTX 1650 GDDR6 | GPU | GALAX GeForce GT 1030 Black DDR4 |
| NVIDIA GeForce GTX 1650 (GDDR6) | Based on | NVIDIA GeForce GT 1030 (DDR4) |
| TU117-300-A1 / TU106-125-A1 / TU116-150-KA-A1 | GPU Chip | GP108-310-A1 |
| Turing | Architecture | Pascal |
| 14 | Streaming Multiprocessors | 3 |
| 896 | Shader | 384 |
| 32 | Render Output Units | 16 |
| 56 | Texture Units | 24 |
| 0 | Raytracing Cores | 0 |
MemoryThe NVIDIA GeForce GTX 1650 GDDR6 is equipped with a 4 GB large GDDR6 graphics memory, which is equipped with 1.500 GHz clocks. The GALAX GeForce GT 1030 Black DDR4 has a 2 GB large DDR4 graphics memory and the memory clock is 1.050GHz. |
||
| 4 GB | Memory Size | 2 GB |
| GDDR6 | Memory Type | DDR4 |
| 1.500 GHz | Memory Clock | 1.050 GHz |
| 12.0 Gbps | Memory Speed | 2.1 Gbps |
| 192 GB/s | Memory bandwidth | 17 GB/s |
| 128 bit | Memory Interface | 64 bit |
Clock SpeedsThe NVIDIA GeForce GTX 1650 GDDR6 has a turbo clock of 1.590 GHz. The turbo frequency of the GALAX GeForce GT 1030 Black DDR4 is 1.379 GHz. |
||
| 1.410 GHz | Base Clock | 1.151 GHz |
| 1.590 GHz | Boost Clock | 1.379 GHz |
| Avg (Game) Clock | ||
| Yes | Overclocking | Yes |
Thermal DesignThe NVIDIA GeForce GTX 1650 GDDR6 has 1 x 6-Pin connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as 92 °C. The GALAX GeForce GT 1030 Black DDR4 is equipped with a PCIe power connector that supplies it with power. The maximum operating temperature of the card is 97 °C. |
||
| 75 W | TDP | 30 W |
| -- | TDP (up) | -- |
| 92 °C | Tjunction max | 97 °C |
| 1 x 6-Pin | PCIe-Power | |
Cooler & FansThe graphics processor and graphics memory of the NVIDIA GeForce GTX 1650 GDDR6 are cooled with a Air cooling. The GALAX GeForce GT 1030 Black DDR4 is cooled by a Air cooling. |
||
| Axial | Fan-Type | Axial |
| -- | Fan 1 | 1 x 80 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| dB | Noise (Idle) | 0 dB |
| -- | Noise (Load) | 0 dB |
ConnectivityThe NVIDIA GeForce GTX 1650 GDDR6 supports the downward compatible copy protection HDCP in version 2.2. The GALAX GeForce GT 1030 Black DDR4 supports HDCP in version 2.2 and all previous versions. |
||
| 3 | Max. Displays | 3 |
| 2.2 | HDCP-Version | 2.2 |
| 1x HDMI v2.0b | HDMI Ports | 1x HDMI v2.0b |
| 1x DP v1.4a | DP Ports | -- |
| 1 | DVI Ports | 1 |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe NVIDIA GeForce GTX 1650 GDDR6 supports the DirectX standard from Microsoft in version 12_1. The GALAX GeForce GT 1030 Black DDR4 supports Microsoft's DirectX version 12_1. |
||
| 7680x4320 | Max. resolution | 4096x2160 |
| 12_1 | DirectX | 12_1 |
| No | Raytracing | No |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | No LED lighting |
Supported Video CodecsThis area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load. |
||
| Decode / Encode | h264 | Decode |
| Decode / Encode | h265 / HEVC | Decode |
| No | AV1 | No |
| Decode | VP8 | No |
| Decode | VP9 | Decode |
DimensionsThe NVIDIA GeForce GTX 1650 GDDR6 is -- wide and therefore needs the space of 2 PCIe-Slots in the case. The width of the GALAX GeForce GT 1030 Black DDR4 is -- and thus requires the space of 2 PCIe-Slots in the PC case. |
||
| 145 mm | Length | -- |
| 111 mm | Height | -- |
| -- | Width | -- |
| 2 PCIe-Slots | Width (Slots) | 2 PCIe-Slots |
| -- | Weight | -- |
| PCIe 3.0 x 16 | GPU Interface | PCIe 3.0 x 4 |
| No | SFF-Ready | No |
Additional dataManufactured using the 12 nanometer process, NVIDIA GeForce GTX 1650 GDDR6 was released in Q2/2020. The GALAX GeForce GT 1030 Black DDR4 published in Q1/2018 is manufactured with a structure width of 14 nanometers. |
||
| -- | Part-no | 30NPG4HV00AB |
| Q2/2020 | Release date | Q1/2018 |
| 149 $ (Reference) | Launch Price | 79 $ (Reference) |
| 12 nm | Structure size | 14 nm |
| data sheet | Documents | data sheet |
1.410 GHz, 4 GB (75 W TDP)
Buy this graphic card at amazon!
1.151 GHz, 2 GB (30 W TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
NVIDIA GeForce GTX 1650 GDDR6
4 GB GDDR6 |
||
|
GALAX GeForce GT 1030 Black DDR4
2 GB DDR4 |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
3840x2160 (2160p)
|
|
NVIDIA GeForce GTX 1650 GDDR6
4 GB GDDR6 |
||
|
|
GALAX GeForce GT 1030 Black DDR4
2 GB DDR4 |
||
2560x1440 (1440p)
|
|
NVIDIA GeForce GTX 1650 GDDR6
4 GB GDDR6 |
||
|
|
GALAX GeForce GT 1030 Black DDR4
2 GB DDR4 |
||
1920x1080 (1080p)
|
|
NVIDIA GeForce GTX 1650 GDDR6
4 GB GDDR6 |
||
|
|
GALAX GeForce GT 1030 Black DDR4
2 GB DDR4 |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
NVIDIA GeForce GTX 1650 GDDR6
4 GB GDDR6 |
||
Geekbench 6 - Vulkan
|
|
NVIDIA GeForce GTX 1650 GDDR6
4 GB GDDR6 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
NVIDIA GeForce GTX 1650 GDDR6
4 GB GDDR6 |
||
|
|
GALAX GeForce GT 1030 Black DDR4
2 GB DDR4 |
||
