The Palit GeForce RTX 2070 GameRock has 2304 shader units and these clock a maximum of 1.73 GHz which results in an FP32 computing power of 7.94 TFLOPS.
The Gainward GeForce RTX 2070 Phantom GLH has 2304 shader units and these clock at a maximum of 1.82 GHz and achieve an FP32 computing power of 8.36 TFLOPS.
Quick comparison
In FP32 performance, the Gainward GeForce RTX 2070 Phantom GLH is 5.3 % faster than the Palit GeForce RTX 2070 GameRock.
The Palit GeForce RTX 2070 GameRock is equipped with a graphics chip of the Turing architecture, which has 36 streaming multiprocessors.
The graphics card Gainward GeForce RTX 2070 Phantom GLH is based on the Turing architecture and is equipped with 36 execution units.
Memory
Memory
Palit GeForce RTX 2070 GameRock
Gainward GeForce RTX 2070 Phantom GLH
Memory Size
8 GB
8 GB
Memory Type
GDDR6
GDDR6
Memory Clock
1.750 GHz
1.750 GHz
Memory Speed
14.0 Gbps
14.0 Gbps
Memory bandwidth
448 GB/s
448 GB/s
Memory Interface
256 bit
256 bit
More information
The Palit GeForce RTX 2070 GameRock is equipped with a 8 GB large GDDR6 graphics memory, which is equipped with 1.750 GHz clocks.
The Gainward GeForce RTX 2070 Phantom GLH has a 8 GB large GDDR6 graphics memory and the memory clock is 1.750GHz.
Clock Speeds
Clock Speeds
Palit GeForce RTX 2070 GameRock
Gainward GeForce RTX 2070 Phantom GLH
Base Clock
1.410 GHz
1.410 GHz
Boost Clock
1.725 GHz+6 %
1.815 GHz+12 %
Overclocking
Yes
Yes
More information
The Palit GeForce RTX 2070 GameRock has a turbo clock of 1.725 GHz. The turbo frequency of the Gainward GeForce RTX 2070 Phantom GLH is 1.815 GHz.
Thermal Design
Thermal Design
Palit GeForce RTX 2070 GameRock
Gainward GeForce RTX 2070 Phantom GLH
TDP
185 W
215 W
Tjunction max
89 °C
89 °C
PCIe-Power
1 x 6-Pin, 1 x 8-Pin
1 x 6-Pin, 1 x 8-Pin
More information
The Palit GeForce RTX 2070 GameRock has 1 x 6-Pin, 1 x 8-Pin connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as 89 °C.
The Gainward GeForce RTX 2070 Phantom GLH is equipped with a 1 x 6-Pin, 1 x 8-Pin PCIe power connector that supplies it with power. The maximum operating temperature of the card is 89 °C.
Cooler & Fans
Cooler & Fans
Palit GeForce RTX 2070 GameRock
Gainward GeForce RTX 2070 Phantom GLH
Fan-Type
Axial
Axial
Fan 1
2 x 100 mm
3 x 90 mm
Cooler-Type
Air cooling
Air cooling
Noise (Idle)
0 dB
0 dB
More information
The graphics processor and graphics memory of the Palit GeForce RTX 2070 GameRock are cooled with a Air cooling.
The Gainward GeForce RTX 2070 Phantom GLH is cooled by a Air cooling.
Connectivity
Connectivity
Palit GeForce RTX 2070 GameRock
Gainward GeForce RTX 2070 Phantom GLH
Max. Displays
4
4
HDCP
2.2
2.2
HDMI
1x HDMI 2.0b
1x HDMI 2.0b
DisplayPort
3x DP 1.4a
3x DP 1.4a
USB-C
1
1
More information
The Palit GeForce RTX 2070 GameRock supports the downward compatible copy protection HDCP in version 2.2.
The Gainward GeForce RTX 2070 Phantom GLH supports HDCP in version 2.2 and all previous versions.
Featureset
Featureset
Palit GeForce RTX 2070 GameRock
Gainward GeForce RTX 2070 Phantom GLH
Max. resolution
7680x4320
7680x4320
DirectX
12_2 (Ultimate)
12_2 (Ultimate)
Raytracing
Yes
Yes
DLSS / FSR
Yes
Yes
LED
No LED lighting
No LED lighting
More information
The Palit GeForce RTX 2070 GameRock supports the DirectX standard from Microsoft in version 12_2 (Ultimate).
The Gainward GeForce RTX 2070 Phantom GLH supports Microsoft's DirectX version 12_2 (Ultimate).
Supported Video Codecs
Supported Video Codecs
Palit GeForce RTX 2070 GameRock
Gainward GeForce RTX 2070 Phantom GLH
h264
Decode / Encode
Decode / Encode
h265 / HEVC
Decode / Encode
Decode / Encode
VP8
Decode
Decode
VP9
Decode
Decode
AV1
No
No
More information
This area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load.
Dimensions
Dimensions
Palit GeForce RTX 2070 GameRock
Gainward GeForce RTX 2070 Phantom GLH
Length
292 mm
292 mm
Height
130 mm
130 mm
Width
60 mm
60 mm
Width (Slots)
3 Slots
3 Slots
SFF-Ready
No
No
More information
The Palit GeForce RTX 2070 GameRock is 60 mm wide and therefore needs the space of 3 PCIe-Slots in the case.
The width of the Gainward GeForce RTX 2070 Phantom GLH is 60 mm and thus requires the space of 3 PCIe-Slots in the PC case.
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
