GPU comparison with benchmarksIn the gpu comparison between the Zotac GeForce GTX 980 OC and the Palit GeForce RTX 4090 GameRock OmniBlack, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe Zotac GeForce GTX 980 OC is based on the NVIDIA GeForce GTX 980 and has 2048 texture shaders and 16 execution units. Palit GeForce RTX 4090 GameRock OmniBlack is based on NVIDIA GeForce RTX 4090, which has 16384 shaders and 128 execution units. |
||
Zotac GeForce GTX 980 OC | GPU | Palit GeForce RTX 4090 GameRock OmniBlack |
NVIDIA GeForce GTX 980 | Based on | NVIDIA GeForce RTX 4090 |
GM204-400-A1 | GPU Chip | AD102-300-A1 |
Maxwell 2.0 | Architecture | Ada Lovelace |
16 | Streaming Multiprocessors | 128 |
2048 | Shader | 16384 |
64 | Render Output Units | 176 |
128 | Texture Units | 512 |
0 | Raytracing Cores | 128 |
MemoryThe Zotac GeForce GTX 980 OC has 4 GB of graphics memory of the type GDDR5 and achieves a memory bandwidth of 224 GB/s. The Palit GeForce RTX 4090 GameRock OmniBlack can access 24 GB GDDR6X graphics memory and thus achieves a memory bandwidth of 1008 GB/s. |
||
4 GB | Memory Size | 24 GB |
GDDR5 | Memory Type | GDDR6X |
1.753 GHz | Memory Clock | 1.313 GHz |
7.0 Gbps | Memory Speed | 21.0 Gbps |
224 GB/s | Memory bandwidth | 1008 GB/s |
256 bit | Memory Interface | 384 bit |
Clock SpeedsThe Zotac GeForce GTX 980 OC clocks in the base with up to 1.139 GHz. The base frequency of the Palit GeForce RTX 4090 GameRock OmniBlack is 2.235 GHz. |
||
1.139 GHz | Base Clock | 2.235 GHz |
1.240 GHz | Boost Clock | 2.520 GHz |
Avg (Game) Clock | ||
Yes | Overclocking | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the Zotac GeForce GTX 980 OC is 165 W. The graphics card is supplied with energy via the 2 x 6-Pin connector. The Palit GeForce RTX 4090 GameRock OmniBlack has a TDP of 450 W and is supplied with the required energy via 1 x 16-Pin PCIe power connectors. |
||
165 W | TDP | 450 W |
-- | TDP (up) | -- |
98 °C | Tjunction max | 90 °C |
2 x 6-Pin | PCIe-Power | 1 x 16-Pin |
Cooler & FansThe Zotac GeForce GTX 980 OC has a total of 1 Radial fans. The Palit GeForce RTX 4090 GameRock OmniBlack has 3 Axial fans to cool the GPU and memory. |
||
Radial | Fan-Type | Axial |
1 x 65 mm | Fan 1 | 3 x 100 mm |
-- | Fan 2 | -- |
Air cooling | Cooler-Type | Air cooling |
0 dB | Noise (Idle) | 0 dB |
-- | Noise (Load) | -- |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 4 screens can be connected to the Zotac GeForce GTX 980 OC. The Palit GeForce RTX 4090 GameRock OmniBlack supports a maximum of 4 screens. |
||
4 | Max. Displays | 4 |
2.2 | HDCP-Version | 2.3 |
1x HDMI v2.0 | HDMI Ports | 1x HDMI v2.1 |
3x DP v1.2 | DP Ports | 3x DP v1.4a |
1 | DVI Ports | -- |
-- | VGA Ports | -- |
-- | USB-C Ports | -- |
FeaturesetThe Zotac GeForce GTX 980 OC supports a maximum resolution of 4096x2160 pixels. The maximum resolution of the Palit GeForce RTX 4090 GameRock OmniBlack is 7680x4320 pixels. |
||
4096x2160 | Max. resolution | 7680x4320 |
12_1 | DirectX | 12_2 (Ultimate) |
No | Raytracing | Yes |
No | DLSS / FSR | Yes |
No LED lighting | LED | Addressable LED |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
Decode / Encode | h264 | Decode / Encode |
No | h265 / HEVC | Decode / Encode |
No | AV1 | Decode |
Decode | VP8 | Decode |
No | VP9 | Decode |
DimensionsThe Zotac GeForce GTX 980 OC is 267 mm long, 111 mm high and 38 mm wide. The Palit GeForce RTX 4090 GameRock OmniBlack is 329 mm long, 138 mm high and 72 mm wide. |
||
267 mm | Length | 329 mm |
111 mm | Height | 138 mm |
38 mm | Width | 72 mm |
2 PCIe-Slots | Width (Slots) | 4 PCIe-Slots |
-- | Weight | -- |
PCIe 3 x 16 | GPU Interface | PCIe 4.0 x 16 |
Additional dataThe Zotac GeForce GTX 980 OC was released in Q3/2014 at a price of 529 $. The Palit GeForce RTX 4090 GameRock OmniBlack was introduced in Q4/2022 at a price of 1,599 $ (Reference). |
||
ZT-90205-10P | Part-no | NED4090019SB-1020Q |
Q3/2014 | Release date | Q4/2022 |
529 $ | Launch Price | 1,599 $ (Reference) |
28 nm | Structure size | 5 nm |
-- | Documents | data sheet |
