INNO3D GeForce RTX 3080 Ti iCHILL Black
Benchmark and Specs
Last updated:
Benchmark and Specs
Here we show you benchmarks and technical data for the INNO3D GeForce RTX 3080 Ti iCHILL Black. The graphics card is based on the NVIDIA GeForce RTX 3080 Ti (Ampere) and has 12 GB GDDR6X graphics memory with a memory bandwidth of 912 GB/s. The INNO3D GeForce RTX 3080 Ti iCHILL Black has 80 execution units with 10240 shaders.
GPUThe INNO3D GeForce RTX 3080 Ti iCHILL Black has 10240 shaders and 80 execution units. The graphics card thus achieves a theoretical FP32 computing power of 35.02 TFLOPS. |
|
| Based on: | NVIDIA GeForce RTX 3080 Ti |
| GPU Chip: | GA102-225-A1 (Ampere) |
| Streaming Multiprocessors: | 80 |
| Shader: | 10240 |
| Render Output Units: | 112 |
| Texture Units: | 320 |
| Raytracing Cores: | 80 |
MemoryThe INNO3D GeForce RTX 3080 Ti iCHILL Black can use 12 GB graphics memory of the type GDDR6X. The graphics card thus achieves a memory bandwidth of 912 GB/s on a 384 bit wide memory interface. |
|
| Memory Size: | 12 GB |
| Memory Type: | GDDR6X |
| Memory Clock: | 1.188 GHz |
| Memory Speed: | 19.0 Gbps |
| Memory bandwidth: | 912 GB/s |
| Memory Interface: | 384 bit |
Clock SpeedsThe base clock frequency of the INNO3D GeForce RTX 3080 Ti iCHILL Black is 1.365 GHz. A high clock frequency (even in turbo mode) can greatly increase the speed of a graphics card. |
|
| Base Clock: | 1.365 GHz |
| Boost Clock: | 1.710 GHz + 3 % |
| Avg (Game) Clock: | |
| Overclocking: | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the INNO3D GeForce RTX 3080 Ti iCHILL Black is 350 W. The graphics card is supplied with energy via the 2 x 8-Pin connector. |
|
| TDP: | 350 W |
| TDP (up): | -- |
| Tjunction max: | 93 °C |
| PCIe-Power: | 2 x 8-Pin |
Cooler & FansThe INNO3D GeForce RTX 3080 Ti iCHILL Black has a total of 2 Axial (Card/Radiator) fans to cool the graphics processor and graphics memory. |
|
| Fan-Type: | Axial (Card/Radiator) |
| Fan 1: | 1 x 90 mm |
| Fan 2: | 1 x 120 mm |
| Cooler-Type: | AIO water cooling |
| Noise (Idle): | 0 dB / Silent |
| Noise (Load): | -- |
ConnectivityUp to 4 screens can be connected to the INNO3D GeForce RTX 3080 Ti iCHILL Black. |
|
| Max. Displays: | 4 |
| HDCP-Version: | 2.3 |
| HDMI Ports: | 1x HDMI v2.1 |
| DP Ports: | 3x DP v1.4a |
| DVI Ports: | -- |
| VGA Ports: | -- |
| USB-C Ports: | -- |
FeaturesetThe INNO3D GeForce RTX 3080 Ti iCHILL Black has a maximum resolution of 7680x4320 pixels. The graphics card supports the DirectX 12_2 (Ultimate) standard. |
|
| Max. resolution: | 7680x4320 |
| DirectX: | 12_2 (Ultimate) |
| Raytracing: | Yes |
| DLSS / FSR: | Yes |
| LED: | ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light |
Supported Video CodecsThe video codecs accelerated in hardware by the INNO3D GeForce RTX 3080 Ti iCHILL Black reduce the processor load and ensure lower energy consumption. |
|
| h264: | Decode / Encode |
| h265 / HEVC: | Decode / Encode |
| VP8: | Decode |
| VP9: | Decode |
| AV1: | Decode |
DimensionsThe INNO3D GeForce RTX 3080 Ti iCHILL Black is 226 mm long and 119 mm high. With a width of --, the graphics card requires 3 PCIe-Slots in the case. |
|
| Length: | 226 mm |
| Height: | 119 mm |
| Width: | -- |
| Width (Slots): | 3 PCIe-Slots |
| Weight: | -- |
Additional dataThe INNO3D GeForce RTX 3080 Ti iCHILL Black made in 8 nm was published in Q3/2021 for 1,199 $ (Reference). |
|
| GPU Interface: | PCIe 4.0 x 16 |
| Release date: | Q3/2021 |
| Launch Price: | 1,199 $ (Reference) |
| Structure size: | 8 nm |
| Part-no: | C308TB-126XX-1810003 |
| Documents: | data sheet |
