GPUThe Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) is equipped with 60 execution and 7680 shader units. With single precision, a theoretical FP32 computing power of 40.09 TFLOPS is achieved. |
|
Based on: | NVIDIA GeForce RTX 4070 Ti |
GPU Chip: | AD104-400-A1 (Ada Lovelace) |
Streaming Multiprocessors: | 60 |
Shader: | 7680 |
Render Output Units: | 80 |
Texture Units: | 240 |
Raytracing Cores: | 60 |
MemoryThe Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) has a 192 bit wide memory interface, with which a memory bandwidth of 504 GB/s is achieved. In total, 12 GB GDDR6X graphics memory is available for the graphics card. |
|
Memory Size: | 12 GB |
Memory Type: | GDDR6X |
Memory Clock: | 1.313 GHz |
Memory Speed: | 21.0 Gbps |
Memory bandwidth: | 504 GB/s |
Memory Interface: | 192 bit |
Clock SpeedsThe manufacturer specifies the memory clock of the Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) with 2.310 GHz (base clock) or with 2.610 GHz (turbo clock). If overclocking is supported (see below), the clock rate can be increased even further. |
|
Base Clock: | 2.310 GHz |
Boost Clock: | 2.610 GHz |
Avg (Game) Clock: | |
Overclocking: | Yes |
Thermal DesignThe Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) has 1 x 16-Pin plugs, which supply the graphics card with energy. The maximum operating temperature of the card is 90 °C. |
|
TDP: | 285 W |
TDP (up): | -- |
Tjunction max: | 90 °C |
PCIe-Power: | 1 x 16-Pin |
Cooler & FansThe Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) is equipped with 3 Axial main fans, which are used to cool the graphics processor and graphics memory. |
|
Fan-Type: | Axial |
Fan 1: | 3 x 90 mm |
Fan 2: | -- |
Cooler-Type: | Air cooling |
Noise (Idle): | 0 dB / Silent |
Noise (Load): | -- |
ConnectivityUp to 4 screens can be connected to the Manli GeForce RTX 4070 Ti Gallardo (M3542+N693), whereby the backward-compatible HDCP copy protection is supported in the 2.3 version. |
|
Max. Displays: | 4 |
HDCP-Version: | 2.3 |
HDMI Ports: | 1x HDMI v2.1 |
DP Ports: | 3x DP v1.4a |
DVI Ports: | -- |
VGA Ports: | -- |
USB-C Ports: | -- |
FeaturesetThe Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) supports a maximum resolution of 7680x4320 pixels and the DirectX standard version 12_2 (Ultimate). |
|
Max. resolution: | 7680x4320 |
DirectX: | 12_2 (Ultimate) |
Raytracing: | Yes |
DLSS / FSR: | Yes |
LED: | Addressable LED |
Supported Video CodecsHere is a list of which video codecs can be decoded / encoded by the Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) in hardware in order to minimize the processor load. |
|
h264: | Decode / Encode |
h265 / HEVC: | Decode / Encode |
VP8: | Decode |
VP9: | Decode |
AV1: | Decode |
DimensionsThe dimensions of the Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) are 315 mm in length, 125 mm in height and 66 mm in width. Thus 4 PCIe-Slots are needed in a case. |
|
Length: | 315 mm |
Height: | 125 mm |
Width: | 66 mm |
Width (Slots): | 4 PCIe-Slots |
Weight: | -- |
Additional dataThe Manli GeForce RTX 4070 Ti Gallardo (M3542+N693) is manufactured in a structure width of 5 nm and has a PCIe 4.0 x 16 lanes interface. The graphics card was released in Q1/2023. |
|
GPU Interface: | PCIe 4.0 x 16 |
Release date: | Q1/2023 |
Launch Price: | 799 $ (Reference) |
Structure size: | 5 nm |
Part-no: | M-NRTX4070TIG/6RFHPPP-M3542 |
Documents: | data sheet |
