The ZOTAC GAMING GeForce RTX 5070 SOLID OC has 48 execution units with 6144 shaders. This gives the graphics card a theoretical FP32 computing power of 31.23 TFLOPS.
- GPU Chip
- GB205-300-A1 (Blackwell)
- Streaming Multiprocessors
- 48
- Shader
- 6144
- Render Output Units
- 64
- Texture Units
- 192
- Raytracing Cores
- 48
The ZOTAC GAMING GeForce RTX 5070 SOLID OC is equipped with 12 GB graphics memory of the type GDDR7. The memory clock of the graphics card is 1.750 GHz and the speed is 28 Gbps.
- Memory Size
- 12 GB
- Memory Type
- GDDR7
- Memory Clock
- 1.750 GHz
- Memory Speed
- 28.0 Gbps
- Memory bandwidth
- 672 GB/s
- Memory Interface
- 192 bit
The base frequency of this graphics card is 2.165 GHz and the manufacturer specifies the maximum turbo clock as 2.542 GHz. If supported (see below), the performance can be further increased by overclocking.
- Base Clock
- 2.165 GHz
- Boost Clock
- 2.542 GHz+1 %
- Overclocking
- Yes
The ZOTAC GAMING GeForce RTX 5070 SOLID OC is powered by 1 x 16-Pin connectors. The TDP (Thermal Design Power) of the graphics card is 250 W.
- TDP
- 250 W
- Tjunction max
- 85 °C
- PCIe-Power
- 1 x 16-Pin
Graphics processor and graphics memory of the ZOTAC GAMING GeForce RTX 5070 SOLID OC are cooled by a Air cooling.
- Fan-Type
- Axial
- Fan 1
- 3 x 90 mm
- Cooler-Type
- Air cooling
- Noise (Idle)
- 0 dB / Silent
Up to 4 monitors can be operated with the ZOTAC GAMING GeForce RTX 5070 SOLID OC.
- Max. Displays
- 4
- HDCP
- 2.3
- HDMI
- 1x HDMI 2.1b
- DisplayPort
- 3x DP 2.1b
With the ZOTAC GAMING GeForce RTX 5070 SOLID OC it is possible to operate a screen with a resolution of up to 7680x4320 pixels. Furthermore, the DirectX standard version 12_2 (Ultimate) is supported.
- Max. resolution
- 7680x4320
- DirectX
- 12_2 (Ultimate)
- Raytracing
- Yes
- DLSS / FSR
- Yes
- LED
- ZOTAC SPECTRA
This area lists the video codecs that the ZOTAC GAMING GeForce RTX 5070 SOLID OC can decode or encode in hardware in order to minimize the processor load, which leads to lower power consumption.
- h264
- Decode / Encode
- h265 / HEVC
- Decode / Encode
- VP8
- Decode / Encode
- VP9
- Decode / Encode
- AV1
- Decode / Encode
The ZOTAC GAMING GeForce RTX 5070 SOLID OC needs the space of 2 PCIe-Slots in a case. It is 304 mm long, 116 mm high and 42 mm wide.
- Length
- 304 mm
- Height
- 116 mm
- Width
- 42 mm
- Width (Slots)
- 2 PCIe-Slots
- SFF-Ready
- Yes
The ZOTAC GAMING GeForce RTX 5070 SOLID OC was released in Q2/2025 at a price of 549 $. The graphics card manufactured in 5 nm is connected to the system via PCIe 5 x 16 lanes.
- GPU Interface
- PCIe 5 x 16
- Release date
- Q2/2025
- Launch Price
- 549 $ (Reference)
- Structure size
- 5 nm
- Part-no
- ZT-B50700J-10P
