NVIDIA RTX 5880 Ada
vs
NVIDIA RTX 6000 Ada
GPU comparison with benchmarksIn the gpu comparison between the NVIDIA RTX 5880 Ada and the NVIDIA RTX 6000 Ada, we compare both the technical data and the benchmark results of the two graphics cards.
|
||
GPUThe NVIDIA RTX 5880 Ada is based on the NVIDIA RTX 5880 Ada and has 14080 texture shaders and 110 execution units. NVIDIA RTX 6000 Ada is based on NVIDIA RTX 6000 Ada, which has 18176 shaders and 142 execution units. |
||
| NVIDIA RTX 5880 Ada | GPU | NVIDIA RTX 6000 Ada |
| NVIDIA RTX 5880 Ada | Based on | NVIDIA RTX 6000 Ada |
| AD102 | GPU Chip | AD102 |
| Ada Lovelace | Architecture | Ada Lovelace |
| 110 | Streaming Multiprocessors | 142 |
| 14080 | Shader | 18176 |
| 176 | Render Output Units | 192 |
| 440 | Texture Units | 568 |
| 110 | Raytracing Cores | 142 |
MemoryThe NVIDIA RTX 5880 Ada has 48 GB of graphics memory of the type GDDR6 and achieves a memory bandwidth of 864 GB/s. The NVIDIA RTX 6000 Ada can access 48 GB GDDR6 graphics memory and thus achieves a memory bandwidth of 960 GB/s. |
||
| 48 GB | Memory Size | 48 GB |
| GDDR6 | Memory Type | GDDR6 |
| 2.250 GHz | Memory Clock | 2.500 GHz |
| 18.0 Gbps | Memory Speed | 20.0 Gbps |
| 864 GB/s | Memory bandwidth | 960 GB/s |
| 384 bit | Memory Interface | 384 bit |
Clock SpeedsThe NVIDIA RTX 5880 Ada clocks in the base with up to 0.975 GHz. The base frequency of the NVIDIA RTX 6000 Ada is 2.175 GHz. |
||
| 0.975 GHz | Base Clock | 2.175 GHz |
| 2.460 GHz | Boost Clock | 2.535 GHz |
| Avg (Game) Clock | ||
| Yes | Overclocking | Yes |
Thermal DesignThe TDP (Thermal Design Power) of the NVIDIA RTX 5880 Ada is 285 W (Reference). The graphics card is supplied with energy via the 1 x 16-Pin connector. The NVIDIA RTX 6000 Ada has a TDP of 300 W (Reference) and is supplied with the required energy via 1 x 16-Pin PCIe power connectors. |
||
| 285 W (Reference) | TDP | 300 W (Reference) |
| -- | TDP (up) | -- |
| Unknown | Tjunction max | 93 °C |
| 1 x 16-Pin | PCIe-Power | 1 x 16-Pin |
Cooler & FansThe NVIDIA RTX 5880 Ada has a total of 1 Radial fans. The NVIDIA RTX 6000 Ada has 1 Radial fans to cool the GPU and memory. |
||
| Radial | Fan-Type | Radial |
| 1 x 70 mm | Fan 1 | 1 x 70 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| 0 dB | Noise (Idle) | 0 dB |
| -- | Noise (Load) | -- |
ConnectivityIn the connectivity category, we recorded the number of ports on a graphics card. A total of 4 screens can be connected to the NVIDIA RTX 5880 Ada. The NVIDIA RTX 6000 Ada supports a maximum of 4 screens. |
||
| 4 | Max. Displays | 4 |
| 2.3 | HDCP-Version | 2.3 |
| -- | HDMI Ports | -- |
| 4x DP v1.4a | DP Ports | 4x DP v1.4a |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe NVIDIA RTX 5880 Ada supports a maximum resolution of 7680x4320 pixels. The maximum resolution of the NVIDIA RTX 6000 Ada is 7680x4320 pixels. |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | No LED lighting |
Supported Video CodecsThe support and acceleration of certain video codecs directly in the graphics card reduces the load when playing or creating videos. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode / Encode | AV1 | Decode / Encode |
| Decode | VP8 | Decode |
| Decode | VP9 | Decode |
DimensionsThe NVIDIA RTX 5880 Ada is 267 mm long, 112 mm high and -- wide. The NVIDIA RTX 6000 Ada is 267 mm long, 112 mm high and -- wide. |
||
| 267 mm | Length | 267 mm |
| 112 mm | Height | 112 mm |
| -- | Width | -- |
| 2 PCIe-Slots | Width (Slots) | 2 PCIe-Slots |
| -- | Weight | -- |
| PCIe 4.0 x 16 | GPU Interface | PCIe 4.0 x 16 |
| No | SFF-Ready | No |
Additional dataThe NVIDIA RTX 5880 Ada was released in Q1/2023 at a price of 6,999 $ (Reference). The NVIDIA RTX 6000 Ada was introduced in Q1/2023 at a price of 6,799 $ (Reference). |
||
| -- | Part-no | -- |
| Q1/2023 | Release date | Q1/2023 |
| 6,999 $ (Reference) | Launch Price | 6,799 $ (Reference) |
| 5 nm | Structure size | 5 nm |
| data sheet | Documents | data sheet |
0.975 GHz, 48 GB (-- TDP)
Buy this graphic card at amazon!
2.175 GHz, 48 GB (-- TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Port Royal (Raytracing)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Speed Way Graphics Score (Raytracing)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
3840x2160 (2160p)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
1920x1080 (1080p)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Geekbench 6 - Vulkan
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
NVIDIA RTX 5880 Ada
48 GB GDDR6 |
||
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
