NVIDIA RTX 6000 Ada
vs
NVIDIA RTX 5000 Ada
GPU comparison with benchmarksThe NVIDIA RTX 6000 Ada has 18176 shader units and these clock a maximum of 2.54 GHz which results in an FP32 computing power of 92.15 TFLOPS.
The NVIDIA RTX 5000 Ada has 12800 shader units and these clock at a maximum of 2.55 GHz and achieve an FP32 computing power of 65.28 TFLOPS. |
||
GPUThe NVIDIA RTX 6000 Ada is equipped with a graphics chip of the Ada Lovelace architecture, which has 142 streaming multiprocessors. The graphics card NVIDIA RTX 5000 Ada is based on the Ada Lovelace architecture and is equipped with 100 execution units. |
||
| NVIDIA RTX 6000 Ada | GPU | NVIDIA RTX 5000 Ada |
| NVIDIA RTX 6000 Ada | Based on | NVIDIA RTX 5000 Ada |
| AD102 | GPU Chip | AD102 |
| Ada Lovelace | Architecture | Ada Lovelace |
| 142 | Streaming Multiprocessors | 100 |
| 18176 | Shader | 12800 |
| 192 | Render Output Units | 176 |
| 568 | Texture Units | 400 |
| 142 | Raytracing Cores | 100 |
MemoryThe NVIDIA RTX 6000 Ada is equipped with a 48 GB large GDDR6 graphics memory, which is equipped with 2.500 GHz clocks. The NVIDIA RTX 5000 Ada has a 32 GB large GDDR6 graphics memory and the memory clock is 2.250GHz. |
||
| 48 GB | Memory Size | 32 GB |
| GDDR6 | Memory Type | GDDR6 |
| 2.500 GHz | Memory Clock | 2.250 GHz |
| 20.0 Gbps | Memory Speed | 18.0 Gbps |
| 960 GB/s | Memory bandwidth | 576 GB/s |
| 384 bit | Memory Interface | 256 bit |
Clock SpeedsThe NVIDIA RTX 6000 Ada has a turbo clock of 2.535 GHz. The turbo frequency of the NVIDIA RTX 5000 Ada is 2.550 GHz. |
||
| 2.175 GHz | Base Clock | 1.155 GHz |
| 2.535 GHz | Boost Clock | 2.550 GHz |
| Avg (Game) Clock | ||
| Yes | Overclocking | Yes |
Thermal DesignThe NVIDIA RTX 6000 Ada has 1 x 16-Pin connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as 93 °C. The NVIDIA RTX 5000 Ada is equipped with a 1 x 16-Pin PCIe power connector that supplies it with power. The maximum operating temperature of the card is Unknown. |
||
| 300 W (Reference) | TDP | 250 W (Reference) |
| -- | TDP (up) | -- |
| 93 °C | Tjunction max | Unknown |
| 1 x 16-Pin | PCIe-Power | 1 x 16-Pin |
Cooler & FansThe graphics processor and graphics memory of the NVIDIA RTX 6000 Ada are cooled with a Air cooling. The NVIDIA RTX 5000 Ada is cooled by a Air cooling. |
||
| Radial | Fan-Type | Radial |
| 1 x 70 mm | Fan 1 | 1 x 70 mm |
| -- | Fan 2 | -- |
| Air cooling | Cooler-Type | Air cooling |
| 0 dB | Noise (Idle) | 0 dB |
| -- | Noise (Load) | -- |
ConnectivityThe NVIDIA RTX 6000 Ada supports the downward compatible copy protection HDCP in version 2.3. The NVIDIA RTX 5000 Ada supports HDCP in version 2.3 and all previous versions. |
||
| 4 | Max. Displays | 4 |
| 2.3 | HDCP-Version | 2.3 |
| -- | HDMI Ports | -- |
| 4x DP v1.4a | DP Ports | 4x DP v1.4a |
| -- | DVI Ports | -- |
| -- | VGA Ports | -- |
| -- | USB-C Ports | -- |
FeaturesetThe NVIDIA RTX 6000 Ada supports the DirectX standard from Microsoft in version 12_2 (Ultimate). The NVIDIA RTX 5000 Ada supports Microsoft's DirectX version 12_2 (Ultimate). |
||
| 7680x4320 | Max. resolution | 7680x4320 |
| 12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
| Yes | Raytracing | Yes |
| Yes | DLSS / FSR | Yes |
| No LED lighting | LED | No LED lighting |
Supported Video CodecsThis area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load. |
||
| Decode / Encode | h264 | Decode / Encode |
| Decode / Encode | h265 / HEVC | Decode / Encode |
| Decode / Encode | AV1 | Decode / Encode |
| Decode | VP8 | Decode |
| Decode | VP9 | Decode |
DimensionsThe NVIDIA RTX 6000 Ada is -- wide and therefore needs the space of 1 PCIe-Slots in the case. The width of the NVIDIA RTX 5000 Ada is -- and thus requires the space of 1 PCIe-Slots in the PC case. |
||
| 267 mm | Length | 267 mm |
| 112 mm | Height | 112 mm |
| -- | Width | -- |
| 2 PCIe-Slots | Width (Slots) | 1 PCIe-Slots |
| -- | Weight | -- |
| PCIe 4.0 x 16 | GPU Interface | PCIe 4.0 x 16 |
| No | SFF-Ready | No |
Additional dataManufactured using the 5 nanometer process, NVIDIA RTX 6000 Ada was released in Q1/2023. The NVIDIA RTX 5000 Ada published in Q3/2023 is manufactured with a structure width of 5 nanometers. |
||
| -- | Part-no | -- |
| Q1/2023 | Release date | Q3/2023 |
| 6,799 $ (Reference) | Launch Price | 3,999 $ (Reference) |
| 5 nm | Structure size | 5 nm |
| data sheet | Documents | data sheet |
2.175 GHz, 48 GB (-- TDP)
Buy this graphic card at amazon!
1.155 GHz, 32 GB (-- TDP)
Buy this graphic card at amazon!
Rate these graphics cards now
Benchmark results
3DMark Benchmark (DirectX, Raytracing)
3DMark is a benchmark program that determines the performance of certain components of a computer and then reports the performance as a numerical value.
Time Spy Extreme Graphics score
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Port Royal (Raytracing)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Speed Way Graphics Score (Raytracing)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Cyberpunk 2077
Cyberpunk 2077 was developed by CD Projekt Red and is based on the development studio's own REDengine 4. Ray tracing is switched off in our benchmarks.
3840x2160 (2160p)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Battlefield 5
Battlefield 5 is a visually stunning game that is ideal as a graphics card benchmark. We test the game with maximum details on Windows 10.
1920x1080 (1080p)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Geekbench 6 (OpenCL, Vulkan, Metal)
Geekbench 6 is a cross-platform benchmark for main processors, which also carries out 3 different graphics benchmarks and outputs them in the form of a numerical value.
Geekbench 6 - OpenCL
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
Geekbench 6 - Vulkan
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
FP32 Performance (Single-precision TFLOPS)
The theoretical computing power of the graphics card with single precision (32 bit) in TFLOPS indicates how many trillion FP32 floating point operations the graphics card (GPU) can perform per second.
FP32 (TFLOPS)
|
|
NVIDIA RTX 6000 Ada
48 GB GDDR6 |
||
|
|
NVIDIA RTX 5000 Ada
32 GB GDDR6 |
||
